| Video/Audio Input |
| IP video input : 8-ch |
| Network |
| Incoming bandwidth : 50Mbps |
| Outgoing bandwidth : 80Mbps |
| Remote connection : 128 |
| Network Protocol : IPv6, UPnP, SNMP, NTP, SADP, DDNS, SMTP, NFS, iSCSI. |
| HDMI output : 1-ch, resolution: 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz,1280 × 720 /60Hz, 1024 × 768 /60Hz |
| Video/Audio Output |
| Recording Resolution : 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback : 8-ch |
| Wireless |
| Frequency Band : 2.4GHz |
| Antenna Structure : 2 × 2MIMO |
| Transmission Rate : 300Mbps |
| Transmission Standard : IEEE 802.1b/g/n |
| Hard Disk |
| SATA : 1 SATA interface for 1 HDD |
| External Interface |
| Network Interface : 1 RJ-45 10 /100 Mbps WAN interface; 3 RJ-45 10 / 100M LAN interfaces. |
| General |
| Power Supply : 12V DC |
| Consumption(without hard disk and POE) : ≤ 12 W |
| Working Temperature : -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
| Working Humidity : 10 % ~ 90 % |
| Dimensions : 87 × 87 × 157 mm (3.4 × 3.4 × 6.2 inch) |
| Weight(without HDD) : ≤ 0.53 Kg (1.2lb) |
