| System |
| Main Processor |
Dual-core embedded processor |
| Operating System |
Embedded LINUX |
| Audio and Video |
| IP Camera Input |
8 Channel |
| Two-way Talk |
Yes |
| Video Encryption |
Optional(-S) |
| Intelligent Video |
Face Recognition, Attendance |
| Face Recognition |
| Performance |
Max 20 face pictures /sec processing |
| 4ch picture stream face recognition |
| Stranger Mode |
Detect strangers' faces (not in device's face database) |
| Similarity threshold can be set manually |
| AI Search |
Search for image by image |
| Search image by properties |
| Database Management |
Up to 16 face databases with 10,000 face images in total |
| Database Application |
Every data can be applied to any channel |
| Trigger Events |
Buzzer, Alarm Out, compare the result simultaneously, etc. |
| Display |
| Interface |
1 HD-OUT, 1 VGA |
| Resolution |
HD-OUT: 3840×2160,1920×1080,1440×900, |
| 1280×1024 |
| VGA: 1920×1080, 1280×1024, 1280×720 |
| Decoding Capacity |
1ch 12MP/4ch 8MP/8ch 4MP@30fps |
| Multi-screen Display |
1.04.2008 |
| Recording |
| Compression |
H.265/H.264 |
| Resolution |
12MP/8MP/6MP/5MP/4MP/3MP/1080P/720P/ D1&etc. |
| Record Rate |
80Mbps |
| Bit Rate |
100Kbps ~ 8Mbps Per Channel |
| Record Mode |
Manual, Schedule (Regular, Continuous), Motion Detection, Video Loss,Camera Tamper, Alarm in |
| Record Interval |
Post-record: 30 ~ 60 sec |
| Video Detection and Alarm |
| Trigger Events |
Recording, Buzzer, Push message, Pop up message. |
| Video Detection |
Motion Detection, Video Loss, Camera Tamper |
| Alarm In/Out |
8/1 |
| Playback and Backup |
| Sync Playback |
8.04.2001 |
| Search Mode |
Time /Date, Alarm, Picture grid, Event |
| Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode |
USB Device |
| Network |
| Interface |
1 RJ-45 port (10M/100Mbps) |
| PoE Interface |
8ch 100Mbps, IEEE802.3af |
| PoE Max Power |
80W |
| Network Function |
HTTP, HTTPS, TCP/IP, IPv4, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, P2P, IP Filter, DDNS, 802.1X, SNMP |
| Optical Fiber Interface |
N/A |
| Max. User |
Access 10 users |
| Smart Phone |
iPhone, iPad, Android |
| Interoperability |
ONVIF, SDK, CGI |
| Storage |
| Internal HDD |
1 SATA Ports, up to 10TB for each HDD |
| Mounting Mode |
Embedded |
| eSATA |
N/A |
| Interface |
| USB |
2 ports (USB 2.0 x1, USB3.0 x1) |
| RS232 |
N/A |
| RS485 |
N/A |
| Audio I/O |
1ch MIC in, 1ch Audio line out |
| Reset Button |
N/A |
| General |
| Power Supply |
DC48V/2.5A |
| Power Consumption |
< 5W (without HDD) |
| Operating Conditions |
-10 °C ~ 50 °C (14 °F ~ 122 °F) |
| Storage Conditions |
Less than 90% RH |
| Certifications |
CE/FCC |
| Dimensions |
255×235×47.5mm |
| Net Weight |
1kg |
