Video/Audio Input |
IP Video Input | 8-ch |
Two-way Audio Input | 1-ch,RCA |
Network |
Incoming Bandwidth | 80Mbps |
Outgoing Bandwidth | 64Mbps |
Remote Users | 128 |
Video/Audio Output |
HDMI/VGA Output | HDMI/VGA: |
1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
Recording Resolution | 4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Audio Output | 1-ch,RCA |
Synchronous Playback | 8-ch |
Decoding |
Compression | H.264 |
Live view/Playback | 4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Capability | 4 x 4MP@20, 8 x 720p@25 |
Hard Disk |
SATA | 1 SATA interface |
Capacity | up to 8TB for each disk |
External Interface |
Network Interface | 1 RJ-45 10M/100M Self-adaptive Ethernet Interface |
USB Interface | Rear panel: 1 x USB2.0, 1 x USB3.0 |
PoE |
Interface | 8 independent 100 Mbps PoEnetwork interfaces |
Supported Standard | IEEE 802.3at |
General |
Power Supply | 48~52V DC |
Consumption | ≤8 W |
Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
Working Humidity | 10% ~ 90% |
Dimensions | 270 × 205 × 42 mm ( 10.6” × 8.1” × 1.7” ) |
Weight ( without HDD ) | ≤ 0.72 Kg ( 1.59 lb ) |
