| Video/Audio Input |
| IP Video Input | 8-ch |
| Two-way Audio Input | 1-ch, RCA |
| Network |
| Incoming Bandwidth | 80Mbps |
| Outgoing Bandwidth | 96Mbps |
| Remote Users | 128 |
| Video/Audio Output |
| HDMI/VGA Output | HDMI/VGA: |
| 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| Recording Resolution | 4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Output | 1-ch, RCA |
| Synchronous Playback | 8-ch |
| Decoding |
| Compression | H.264 |
| Live view | 4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Playback |
| Capability | 2 x 4MP@20, 4 x 1080p@30, 8 x 720p@25 |
| Hard Disk |
| SATA | 2 SATA interfaces |
| Capacity | up to 6TB for each disk |
| External Interface |
| Network Interface | 1 RJ-45 10M/100M/1000M self-adaptive Ethernet Interface |
| USB Interface | Rear panel: 1 x USB2.0, 1 x USB3.0 |
| General |
| Power Supply | 12V DC |
| Consumption | ≤ 8 W |
| Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
| Working Humidity | 10% ~ 90% |
| Dimensions | 44 × 360 × 254mm ( 1.7” × 14.2” × 10.0” ) |
| Weight ( without HDD ) | ≤ 1.42 Kg ( 3.13 lb ) |
