Video/Audio Input |
IP Video Input | 8-ch |
Two-way Audio Input | 1-ch, RCA |
Network |
Incoming Bandwidth | 60Mbps |
Outgoing Bandwidth | 64Mbps |
Remote Users | 128 |
Video/Audio Output |
HDMI/VGA Output | HDMI: |
4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
VGA: |
1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Audio Output | 1-ch, RCA |
Synchronous Playback | 8-ch |
Decoding |
Compression | H.265/H.264 |
Live view | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
/Playback |
Capability | 1 x 4K@30, 2 x 4MP@30, 4 x 1080p@30, 8 x 720p@30, 16 x D1 |
Hard Disk |
SATA | 1 SATA interface |
Capacity | up to 8TB for each disk |
External Interface |
Network Interface | 1 RJ-45 10M/100M self-adaptive Ethernet Interface |
USB Interface | Rear panel:2 x USB2.0,Front panel:1XUSB2.0 |
Alarm In | 4-ch |
Alarm Out | 1-ch |
PoE |
Interface | 8 independent 100 Mbps PoEnetwork interfaces |
Max Power | Max 30W for single port |
Max 108W in total ( 13.5W for each ) |
Supported Standard | IEEE 802.3at, IEEE 802.3af |
General |
Power Supply | 52V DC |
Consumption | ≤ 5 W |
Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
Working Humidity | 10% ~ 90% |
Dimensions | 44 × 260 × 240mm ( 1.7" × 10.2" × 9.4" ) |
Weight ( without HDD ) | ≤ 1.12 Kg ( 2.47 lb ) |
