Video/Audio Input |
IP Video Input | 8-ch |
Two-way Audio Input | 1-ch, RCA |
Network |
Incoming Bandwidth | 80Mbps |
Outgoing Bandwidth | 160Mbps |
Remote Users | 128 |
Video/Audio Output |
HDMI/VGA Output | VGA: |
1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
HDMI: |
4K (3840x2160) /60Hz, 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Audio Output | 1-ch, RCA |
Synchronous Playback | 8-ch |
Decoding |
Compression | H.265/H.264 |
Live view/ | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Playback |
Capability | 4 x 12MP@20, 4 x 4K@30, 8 x 4MP@30, 16 x 1080P@30 |
Hard Disk |
SATA | 2 SATA interfaces |
Capacity | up to 8TB for each disk |
External Interface |
Network Interface | 1 RJ-45 10M/100M/1000M self-adaptive Ethernet Interface |
USB Interface | Front panel: 1 x USB2.0,Rear panel: 1 x USB3.0 |
Alarm In | 4-ch |
Alarm Out | 1-ch |
PoE |
Interface | 8 independent 100 Mbps PoE network interfaces |
Max Power | Max 30W for single port |
Max 130W in total ( 16.25W for each ) |
Supported Standard | IEEE 802.3af/at |
General |
Power Supply | 100 ~ 240 VAC |
Consumption | ≤ 20 W |
Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
Working Humidity | 10% ~ 90% |
Dimensions | 380 mm × 315mm × 46 mm |
Weight ( without HDD ) | ≤2.42kg(5.34lb) |
