| Video/Audio Input |
| IP Video Input | 9-ch |
| Two-way Audio Input | 1-ch, RCA |
| Network |
| Incoming Bandwidth | 90Mbps |
| Outgoing Bandwidth | 180Mbps |
| Remote Users | 128 |
| Video/Audio Output |
| HDMI/VGA Output | HDMI: |
| 4K (3840x2160) /60Hz, 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| VGA: |
| 1920x1080p /60Hz, 1920x1080p /50Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Output | 1-ch, RCA |
| Synchronous Playback | 9-ch |
| Decoding |
| Compression | H.265/H.264 |
| Live View/ Playback | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability | 3 x 12MP@25, 4 x 4K@30, 9 x 4MP@25, 16 x 1080p@30 |
| Hard Disk |
| SATA | 2 SATA interfaces |
| Capacity | up to 8TB for each disk |
| External Interface |
| Network Interface | 2 RJ45 10M/100M/1000M self-adaptive Ethernet Interfaces |
| Serial Interface | 1 x RS485 |
| USB Interface | Front panel: 1 x USB2.0 |
| Rear panel: 1 x USB2.0, 1 x USB3.0 |
| Alarm In | 8-ch |
| Alarm Out | 2-ch |
| General |
| Power Supply | 12V DC |
| Consumption | ≤ 20 W |
| Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
| Working Humidity | 10% ~ 90% |
| Dimensions | 46mm × 315mm × 380mm ( 1.8" × 12.4" × 15.0" ) |
| Weight ( without HDD ) | ≤ 2.48 Kg (5.47 lb ) |
