Özellikler
- Full HD, 1920 x 1080p, 30/25 fps over coax
- Digital Noise Reduction
- Back light compensation for various light conditions
- Power Input AC24V/DC12V
Teknik Özellikler
- Image Sensor: 1/2.8" CMOS Sony Exmor, 2.4 Megapixel
- Pixels - Total: 2000(H) x 1121(V)
- Pixels - Effective: 1984(H) x 1105(V), 2.19M pixels
- Scanning System: Progressive
- Image Size: 1920x1080
- Frame Rate: 30, 25 fps at 1080p
- Sensitivity Colour: 0.5 Lux @ F1.2 (IRE50)
- Sensitivity B&W: 0.01 Lux @ F1.2 (50IRE)
- Sens Up: Off ~ x64
- Video Outputs: 1 Ch HD-SDI BNC or 1 Ch Composite BNC
- S/N Ratio: 48 dB
- Lens Moun: C/CS mount
- Lens Drive Type: DC auto iris, manual iris
- High Speed Shutter: 1/25 ~ 1/60.000 sec
- Shutter Mode: Auto / Fix
- Col/B&W: On/Off/Auto/Ext, IR-cut filter removable (ICR)
- OSD: Yes
- Number of Privacy Zones: 32
- BLC Back Light: WDR / BLC / HLC / OFF
- Digital Noise Reduction (DNR): Off/Low/Mid/High
- Motion Detection: On/ Off/ Sensitivity/ Area setting
- White Balance: ATW, AWB, Manual, Preset
- Serial Interface(s): RS-485
- Protocol: Pelco D, Pelco P
- Alarm: 1 Output
- Operating Temperature: 0°C ~ +60°C
- Storage Temperature: -20°C ~ +60°C
- Humidity: less than 85%
- Supply Voltage: 24 Vac / 12 Vdc
- Power Consumption: 3 W
- Weight: 0.33 kg
- Dimensions w*h*d: 69 x 55x 120.5 mm
Grundig GCH K0303B HD SDI Box Kamera PDF Dosyası445.84 KB
