Özellikler
- Full HD, 1920 x 1080p, 25/30 fps over coax
- Digital Noise Reduction
- Back light compensation for various light conditions
- Wall mounting
- Power Input AC24V/DC12V
Teknik Özellikler
- Image Sensor: 1/2.8″ CMOS Sony Exmor, 2.4 Megapixel
- Pixels – Total: 2000(H) x 1121(V)
- Pixels – Effective: 1984(H) x 1105(V), 2.19M pixels
- Scanning System: Progressive
- Image Size: 1920×1080
- Frame Rate: 30, 25 fps at 1080p
- Sensitivity Colour: 0.5 Lux @ F1.2 (IRE50)
- Sensitivity B&W: 0.3 Lux @ F1.2 (IRE50)
- Sens Up: Off ~ x64
- S/N Ratio: 50 dB
- Video Outputs: 1 Ch HD-SDI BNC or 1 Ch Composite BNC
- Focal Length: 2.8 ~ 10 mm
- Lens Drive Type: DC Auto Iris
- High Speed Shutter: 1/25 ~ 1/60.000 sec
- Shutter Mode: Auto / Fix
- Col/B&W: On/Off/Auto, IR-cut filter removable (ICR)
- OSD: Yes
- Number of Privacy Zones: 32
- BLC: WDR / BLC / HLC / OFF
- Digital Noise Reduction (DNR): Off/Low/Mid/High (Adaptive 3D + 2D)
- Motion Detection: On/ Off/ Sensitivity/ Area setting
- White Balance: ATW, AWB, Manual, Preset
- Protection Rating: IP66 / IK10
- Operating Temperature: -10°C ~ +50°C
- Storage Temperature: -20°C ~ +60°C
- Humidity: less than 85%
- Supply Voltage: 12 VDC/24 VAC
- Power Consumption: 3 W
- Weight: 1.4 kg
- Dimensions w*h*d: Ø150 x 99 mm
Grundig GCH K0323V HD SDI Dome Kamera PDF Dosyası574.17 KB
