Özellikler
- Full HD, 1920 x 1080p, up to 50/60 fps over coax
- WDR (Wide Dynamic Range) for extreme backlight situations
- Video Enhancement: BLC, HLC, DNR
- 0 Lux: Integrated LED IR Illuminator to see even in total darkness
- Smart IR LED Control with adjustable level
- 3 Axis Gimbal, to mount on Wall or Ceiling
- Fast & easy Zoom/Focus adjustment mechanic
- Built-in Service Monitor Port & OSD Control Port
- Power Input AC24V/DC12V
Teknik Özellikler
- Image Sensor: 1/3″ CMOS 2.1 Megapixel
- Pixels – Total: 2010(H) x 1108(V), 2.2M pixels
- Pixels – Effective: 1944(H) x 1092(V), 2.1M pixels
- Scanning System: Progressive
- Image Size: 1920×1080, 1280×720
- Frame Rate: 30/60, 25/50 fps at 1080p; 30/60, 25/50 fps at 720p
- Sensitivity Colour: 0.5 Lux @ F1.2 (IRE50)
- Sensitivity B&W: 0 Lux LED IR on
- Sens Up: x2 ~ x30
- S/N Ratio: >50 dB
- Shutter Speed: AUTO, FLK, 1/25 ~ 1/50.000 Sec., x2 ~ x30
- Col/B&W: On/Off/Auto/Ext, IR-cut filter removable (ICR)
- Focal Length: 2.8 ~ 10 mm
- Lens Drive Type: DC Auto Iris
- IR LED: 28 pcs.
- Smart IR: Off / On
- Max. IR Distance: 30/45 m (according to scene reflexion)
- OSD: Yes, multi language
- Camera ID: 15 character, On / Off
- Flip/Mirror: On/Off
- WDR: Off/Low/Middle/High
- Number of Privacy Zones: 8 (polygonal method)
- BLC Back Light: BLC, HSBLC, OFF
- Digital Noise Reduction (DNR): 2DNR/3DNR (Off/On)
- Motion Detection: On/ Off/ Sensitivity/ Area setting
- Sharpness: Off / On (0~15)
- Digital Zoom: Off/x2 ~ x62
- White Balance: ATW, AWB, AWC, Manual
- De-Fog: Off/On Area Setting
- Dead Pixel Compensation (DPC): Live (On/Off/Auto), Static (On/Off)
- Video Outputs: 1 Ch HD-SDI BNC or 1 Ch Composite BNC
- Operating Temperature: -10°C ~ +50°C
- Storage Temperature: -20°C ~ +60°C
- Humidity: less than 85%
- Supply Voltage: 24 Vac / 12 Vdc
- Power Consumption: 9 W
- Weight: 0.5 kg
- Dimensions w*h*d: Ø 132 x 100 mm
Grundig GCH K1327D 1 HD SDI Dome Kamera PDF Dosyası1.02 MB
