| Camera |
| Image Sensor | 1/2.8" CMOS |
| Effective Pixels | 1920(H)×1080(V), 2MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/3s~1/100,000s |
| NTSC: 1/4s~1/100,000s |
| Minimum Illumination | 0.004Lux/F2.0, 30IRE, 0Lux IR on |
| IR Distance | Up to 40m (131feet) |
| IR On/Off Control | Auto / Manual |
| IR LEDs | 2 |
| Lens |
| Lens Type | Fixed lens / Fixed iris |
| Mount Type | M12 |
| Focal Length | 2.8mm; 3.6mm |
| Max Aperture | F2.0 |
| Angle of View | 2.8mm: 121° x 102° x 57° (diagonal x horizontal x vertical) |
| 3.6mm: 103.6° x 86.9° x 46.3° (diagonal x horizontal x vertical) |
| Close Focus Distance | 500 mm/900 mm |
| Pan / Tilt / Rotation |
| Pan/Tilt/Rotation | Pan: 0° ~ 355° |
| Tilt: 0° ~ 180° |
| Rotation: 0° ~ 355° |
| Video |
| Resolution | 1080P (1920×1080); 720P (1280×720); 960H (704×576/704×480) |
| Frame Rate | CVI: |
| PAL: 1080P@25fps, 720P@25fps, 720P@50fps; |
| NTSC: 1080P@30fps, 720P@30fps, 720P@60fps |
| AHD: |
| PAL: 1080P@25fps, 720P@25fps; |
| NTSC: 1080P@30fps, 720P@30fps |
| TVI: |
| PAL: 1080P@25fps, 720P@25fps, 720P@50fps; |
| NTSC: 1080P@30fps, 720P@30fps, 720P@60fps |
| CVBS |
| PAL: 960 × 576H; |
| NTSC: 960 × 480H |
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Day/Night | Auto (ICR) / Manual |
| OSD Menu | Multi-language |
| BLC Mode | BLC / HLC / WDR |
| WDR | 120dB |
| Gain Control | Auto/Manual |
| Noise Reduction | 2D/3D |
| White Balance | Auto / Manual |
| Smart IR | Auto / Manual |
| DORI Distance |
| Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively. |
| | Distance |
| Detect | 2.8mm: 38.6 m(127 ft) |
| 3.6mm: 55.2 m(181 ft) |
| Observe | 2.8mm: 15.4 m(51 ft) |
| 3.6mm: 22.1 m(73ft) |
| Recognize | 2.8mm: 7.7 m(25 ft) |
| 3.6mm: 11.0 m(36ft) |
| Identify | 2.8mm: 3.9 m(13 ft) |
| 3.6mm: 5.5 m(18ft) |
| Certifications |
| Certifications | CE (EN55032, EN55024, EN50130-4) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) |
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
| Eelectrical |
| Power Supply | 12V DC ±30% |
| Power Consumption | Max 4.1W (12V DC, IR on) |
| Environmental | |
| Operating Conditions | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH |
| * Start up should be done at above -40°C (-40°F) |
| Storage Conditions | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH |
| Ingress Protection & Vandal Resistance | IP67 |
| Construction |
| Casing | Metal front face + plastic main body + plastic bracket |
| Dimensions | 198.9 mm × 80.2 mm × 76.2 mm (7.83" × 3.16" × 3.00") |
| Net Weight | 0.29kg (0.64lb) |
| Gross Weight | 0.44kg (0.97lb) |
