| Camera |
| Image Sensor |
1/2.7" CMOS |
| Effective Pixels |
1920(H)×1080(V), 2MP |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
PAL: 1/25~1/100000s |
| NTSC: 1/30~1/100000s |
| Minimum Illumination |
0.02Lux/F1.85, 30IRE, 0Lux IR on |
| S/N Ratio |
More than 65dB |
| IR Distance |
Up to 30m (98feet) |
| IR On/Off Control |
Auto / Manual |
| IR LEDs |
18 |
| Lens |
| Lens Type |
Fixed lens / Fixed iris |
| Mount Type |
Board-in |
| Focal Length |
3.6mm (2.8mm, 6mm Optional) |
| Max Aperture |
F1.85 |
| Angle of View |
H: 87.5° (103°, 54.7°) |
| Focus Control |
N/A |
| Close Focus Distance |
500mm (900mm, 2000mm) |
| |
19.69'' (35.43", 78.74'') |
| Pan / Tilt / Rotation |
| Pan/Tilt/Rotation |
Pan: 0° ~ 360° |
| Tilt: 0° ~ 90° |
| Rotation: 0° ~ 360° |
| Video |
| Resolution |
1080P (1920×1080) |
| Frame Rate |
25/30fps@1080P, 25/30/50/60fps@720P |
| Video Output |
1-channel BNC high definition video output / CVBS video output (Can switch) |
| Day/Night |
Auto (ICR) / Manual |
| OSD Menu |
Multi-language |
| BLC Mode |
BLC / HLC / DWDR |
| WDR |
DWDR |
| Gain Control |
AGC |
| Noise Reduction |
2D |
| White Balance |
Auto / Manual |
| Smart IR |
Auto / Manual |
| Certifications |
| Certifications |
CE (EN55032, EN55024, EN50130-4) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) |
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
| Interface |
| Audio Interface |
N/A |
| Eelectrical |
| Power Supply |
12V DC ±30% |
| Power Consumption |
Max 4.3W (12V DC, IR on) |
| Environmental |
| Operating Conditions |
-40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH |
| * Start up should be done at above -40°C (-40°F) |
| Storage Conditions |
-40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH |
| Ingress Protection & Vandal Resistance |
IP67 |
| Construction |
| Casing |
Aluminium |
| Dimensions |
164.7mm×70mm×71.6mm (6.48"×2.76"×2.82") |
| Net Weight |
0.37kg (0.82lb) |
| Gross Weight |
0.46kg (1.01lb) |
