| Camera |
| Image Sensör |
1/2.7 inch CMOS |
| Effective Pixels |
2560 (H) x 1440 (V), 4MP |
| Electrical Shutter Speed |
PAL: 1/25s–1/100000s |
| NTSC: 1/30s–1/100000s |
| Mınumum Illumination |
0.03Lux/F2.0,30IRE, 0Lux IR on |
| IR Distance |
30m (98.42ft) |
| IR On/Off Control |
Auto: manual |
| IR LEDs Number |
1 |
| Pan /Tilt/Rotation Range |
Pan: 0°–360° |
| Tilt: 0°–78° |
| Rotation: 0°–360° |
| Lens |
| Lens Type |
Fixel focal |
| Mount Type |
M12 |
| Focal Length |
2.8mm, 3.6mm |
| Max. Aperture |
F2.0/F2.0 |
| Angle of View |
2.8mm: 115.0°×97.0°×52.0° |
| (diagonal×horizontal×vertical) |
| 3.6mm: 89.5°×76.4°×41.6° |
| (diagonal×horizontal×vertical) |
| Iris Type |
Fixed iris |
| Close Focus Distance |
0.8m (2.62ft)/1.4m (4.59ft) |
| DORI Dıstance |
2.8mm:D:56m(184ft);O:22m(72ft);R:11m(36ft),I:6 m(20ft); 3.6mm:D:80m(262ft),O:32m(105ft),R:16m(52ft),I:8 m(26ft); |
| Video |
| Video Frame Rate |
CVI: |
| PAL: 4M@25fp; 1080P@25fp |
| NTSC: 4M@30fp; 1080P@30fp |
| AHD: |
| PAL: 4M@25fp |
| NTSC: 4M@30fp |
| TVI: |
| PAL: 4M@25fp |
| NTSC: 4M@30fp |
| CVBS: |
| PAL: 960H |
| NTSC: 960H |
| Resolution |
4M (2560×1440); 1080P (1920×1080); 960H (960× 576/960×480) |
| Day/Night |
Auto switch by ICR |
| BLC |
BLC /HLC/DWDR |
| WDR |
DWDR |
| White Balance |
Auto/manual |
| Gain Control |
Auto/manual |
| Noise Reduction |
2DNR |
| Smart IR |
yes |
| Mirror |
Off/On |
| Privacy Masking |
Off/On (8 area, rectangle) |
| Certifications |
| Certifications |
CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
| Port |
|
| Video Port |
Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Audio Port |
Built-in mic (-A) |
| Power |
| Power Supply |
12V±30% DC |
| Power Consumption |
Max 4W (12V DC, IR on) |
| Environmental |
| Operating Temperature |
-40°C to +60°C (-40°F to +140°F); <95% (noncondensation) |
| Storage Temperature |
-40°C to +60°C (-40°F to +140°F); <95% (noncondensation) |
| Protection Grade |
IP67 |
| Structure |
| Casing |
Inner core : Metal+plastic : cover : plastic |
| Dimensions |
Φ97.0mm×85.8mm (Φ3.82"×3.38") |
| Net Weight |
0.22kg (0.49lb) |
| Gross Weight |
0.28kg (0.62lb) |
