| Camera |
| Image Sensor |
1/2.7 inch CMOS |
| Max. Resolution |
2880 (H) × 1620 (V) |
| Pixel |
5MP |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
PAL: 1/25 s–1/100000 s |
| NTSC: 1/30 s–1/100000 s |
| S/N Ratio |
> 65 dB |
| Min. Illumination |
0.005 Lux/F1.6, 30IRE, 0 Lux IR on |
| Illumination Distance |
60 m (196.9 ft) |
| Illuminator On/Off Control |
Auto; manual |
| Illuminator Number |
2 |
| Pan/Tilt/Rotation Range |
Pan: 0°–360° |
| Tilt: 0°–78° |
| Rotation: 0°–360° |
| Lens |
| Lens Type |
Motorized vari-focal |
| Auto Focus |
N/A |
| Mount Type |
φ14 |
| Focal Length |
2.7 mm–12 mm |
| Max. Aperture |
F1.6 |
| Field of View |
Diagonal: 39°–130° |
| Horizontal: 34°–107° |
| Vertical: 19°–55° |
| Iris Type |
Fixed iris |
| Close Focus Distance |
0.5 m (1.64 ft) |
| DORI Distance |
|
Detect |
Observe |
Recognize |
Identify |
| 2.7 mm |
69 m (226.37 ft) |
27.6 m (90.55 ft) |
13.8 m (45.27 ft) |
6.9 m (22.63 ft) |
| 12 mm |
191.6 m (628.6 ft) |
76.64 m (251.44 ft) |
38.32 m (125.72 ft) |
19.16 m (62.86 ft) |
| Video |
| Frame Rate |
CVI: |
| PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps |
| NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps |
| AHD: |
| PAL: 4M@25 fps; |
| NTSC: 4M@30 fps |
| TVI: |
| PAL: 4M@25 fps; |
| NTSC: 4M@30 fps |
| CVBS: |
| PAL: 960H; |
| NTSC: 960H |
| Resolution |
5M (2880 × 1620); 4M (2560 × 1440); 1080p (1920 × 1080); 960H (960 × 576/960 × 480) |
| Day/Night |
Auto switch by ICR |
| BLC |
BLC/HLC/DWDR |
| WDR |
DWDR |
| White Balance |
Auto; manual |
| Gain Control |
Auto; manual |
| Noise Reduction |
2D NR |
| Smart IR |
Yes |
| Mirror |
Off/On |
| Privacy Masking |
Off/On (8 area, rectangle) |
| Certifications |
| Certifications |
CE (EN55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN55024:2010+A1:2015, EN 55035:2017, EN50130-4:2011+A1:2014, EN 62368-1:2014+A11:2017) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) |
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
| Port |
| Audio Output |
One channel built-in mic |
| Video Output |
Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Power |
| Power Supply |
AC 24V ±25% / DC 12V ±10% |
| Power Consumption |
Max 8.2W (12V DC, IR on) |
| Environment |
| Operating Temperature |
–30°C to +60°C (–22°F to +140°F); <95% (non-condensation) |
| Storage Temperature |
–30°C to +60°C (–22°F to +140°F); <95% (non-condensation) |
| Protection Grade |
IP67 |
| Structure |
| Casing |
Metal dome+metal cover+plastic decorative ring |
| Camera Dimensions |
φ135 mm × 109 mm (φ5.31" × 4.28") |
| Net Weight |
0.52 kg (1.15 lb) |
| Gross Weight |
0.62 kg (1.37 lb) |
