MOXA EDS G512E 8PoE 4GSFP T 10/100/1000 Endüstriyel PoE Switch
Özellikler
- 8 10/100/1000BaseT(X) ports and 4 100/1000BaseSFP ports
- 8 IEEE 802.3af and IEEE 802.3at PoE+ standard ports
- 36-watt output per PoE+ port in high-power mode
- Intelligent PoE power management functions
- Operate with 240 watts full PoE+ loading at -40 to 75°C
- Turbo Ring and Turbo Chain (recovery time < 20 ms @ 250 switches), RSTP/STP, and MSTP for network redundancy
- Security features based on IEC-62443
- Supports MXstudio for easy, visualized industrial network management
- V-ON™ ensures millisecond-level multicast data and video network recovery
Teknik Özellikler
Technology | |
Standards | IEEE 802.3af/at for Power-over-Ethernet |
IEEE 802.3 for 10BaseT | |
IEEE 802.3u for 100BaseT(X) and 100BaseFX | |
IEEE 802.3ab for 1000BaseT(X) | |
IEEE 802.3z for 1000BaseX | |
IEEE 802.3x for Flow Control | |
IEEE 802.1D-2004 for Spanning Tree Protocol | |
IEEE 802.1w for Rapid STP | |
IEEE 802.1s for Multiple Spanning Tree Protocol | |
IEEE 802.1Q for VLAN Tagging | |
IEEE 802.1p for Class of Service | |
IEEE 802.1X for Authentication | |
IEEE 802.3ad for Port Trunk with LACP | |
Software Features | |
Management | IPv4/IPv6, SNMP v1/v2c/v3, LLDP, Port Mirror, DDM, RMON, DHCP Server/Client, DHCP Option 66/67/82, BootP, TFTP, SMTP, RARP, Telnet, Syslog, SNMP Inform, Flow Control, Back Pressure Flow Control |
Filter | 802.1Q VLAN, Port-Based VLAN, GVRP, IGMP v1/v2/v3, GMRP |
Redundancy Protocols | STP, RSTP, MSTP, Turbo Ring v1/v2, Turbo Chain, Link Aggregation |
Security | RADIUS, TACACS+, MAB Authentication, HTTPS, SSL, SSH, Broadcast Storm Protection, Port Lock, MAC ACL, MAC Sticky, NTP Authentication, SMTP with TLS |
Time Management | SNTP, NTP Server/Client, IEEE 1588v2 PTP (software-based) |
Industrial Protocols | EtherNet/IP, Modbus/TCP, PROFINET IO |
MIB | MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, Q-BRIDGE MIB, Bridge MIB, RSTP MIB, RMON MIB Group 1, 2, 3, 9 |
Switch Properties | |
Priority Queues | 4 |
Max. Number of VLANs | 256 |
VLAN ID Range | VID 1 to 4094 |
IGMP Groups | 2048 |
MAC Table Size | 8 K |
Packet Buffer Size | 1 Mbit |
Jumbo Frame Size | 9.6 KB |
Interface | |
RJ45 Ports | 10/100/1000BaseT(X) auto negotiation speed |
Fiber Ports | 100/1000BaseSFP slot |
Console Port | USB-serial console (Type B connector) |
Storage Port | USB storage (Type A connector for ABC-02-USB) |
PoE Pinout | V+, V+, V-, V-, for pin 1, 2, 3, 6 (Endspan, MDI, Mode A) |
DIP Switches | Turbo Ring, Master, Coupler, Reserve |
Alarm Contact | 1 relay output with current carrying capacity of 1 A @ 24 VDC |
Digital Inputs | 1 input with the same ground, but electrically isolated from the electronics.• +13 to +30 V for state “1” |
• -30 to +3 V for state “” | |
• Max. input current: 8 mA | |
Button | Reset button |
Power Requirements | |
Input Voltage | 48 VDC, redundant dual inputs |
Operating Voltage | 44 to 57 VDC (> 50 VDC for PoE+ output recommended) |
Input Current | 5.42 A @ 48 VDC |
Overload Current Protection | Present |
Connection | 2 removable 4-contact terminal blocks |
Reverse Polarity Protection | Present |
Note | When selecting power supply, check the PD power consumption. |
Power Consumption | Max. 20.16 W full loading without PDs' consumption |
Power Budget | Max. 240 W for total PD consumption |
Max. 36 W for each PoE port | |
Physical Characteristics | |
Housing | Metal |
IP Rating | IP30 protection |
Dimensions | 79.2 x 135 x 137 mm (3.1 x 5.3 x 5.4 in) |
Weight | 1540 g (3.40 lb) |
Installation | DIN-rail mounting, wall mounting (with optional kit) |
Environmental Limits | |
Operating Temperature | Standard Models: -10 to 60°C (14 to 140°F) |
Wide Temp. Models: -40 to 75°C (-40 to 167°F) | |
Storage Temperature | -40 to 85°C (-40 to 185°F) |
Ambient Relative Humidity | 5 to 95% (non-condensing) |
Standards and Certifications | |
Note | Please check Moxa’s website for the most up-to-date certification status. |
Safety | UL 508, EN60950-1 (LVD) |
EMC | EN 61000-6-2/6-4 |
EMI | CISPR 22, FCC Part 15B Class A |
EMS | IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV |
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m | |
IEC 61000-4-4 EFT: Power: 4 kV; Signal: 4 kV | |
IEC 61000-4-5 Surge: Power: 4 kV; Signal: 4 kV | |
IEC 61000-4-6 CS: Signal: 10 kV | |
IEC 61000-4-8 | |
Electrical Substations | IEC 61850-3, IEEE 1613 |
Traffic Control | NEMA TS2 |
Rail Traffic | EN 50121-4 |
Shock | IEC 60068-2-27 |
Freefall | IEC 60068-2-32 |
Vibration | IEC 60068-2-6 |
MTBF (mean time between failures) | |
Time | 361,368 hrs. |
Standard | Telcordia (Bellcore), GB |
Teknik Kısa
PoE : PoE Plus
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir
Aktarım Port Sayısı : 4
Aktarım Türü : 10Gbit Fiber
Montaj Tipi : Rack Mount
PoE Port Sayısı : 8 Port
PoE Güç Bütçesi : 200-400 Watt
Montaj Tipi : Wall Mount
