ONV ONV-IPS31032PF Endüstriyel PoE Switch

Özellikler

Unmanaged industrial PoE fiber switch with 2*10/100M PoE port and 1*155M SC port.
Port 1-2 can support PoE IEEE802.3af/at.
By default, the SC port 1310mm/20km single-mode dual fiber module.
It can support dual DC redundant power input (Phoenix terminal connection) and DIN rail mounting.

Teknik Özellikler

Model	ONV-IPS31032PF
Interface Characteristics
Fixed Port	2*10/100Base-TX PoE ports (Data/Power)
	1*155M uplink SC port (Data)
	2 set of V+, V- redundant DC power interface (5 Pin Phoenix terminal)
Twisted Pair Transmission	10BASE-T: Cat3,4,5 UTP(≤100 meter)
Twisted Pair Transmission	100BASE-T: Cat5e or later UTP(≤100 meter)
Ethernet Port	10/100Base-TX auto-sensing, Full/half duplex MDI/MDI-X self-adaption
SFP Slot Port	The default optical module is single-mode dual-fiber 20km, SC interface.
Optical Cable/ Distance	Multi-mode: 850nm/ 0~500M; 1310nm /0~2kM
Optical Cable/ Distance	Single-mode: 1310nm/ 0~40KM,1550nm /0-120KM.
Chip Parameter
Network Protocol	IEEE802.3 10BASE-T, IEEE802.3i 10Base-T
Network Protocol	IEEE802.3u 100Base-TX, IEEE802.3u 100Base-FX, IEEE802.3x
Forwarding Mode	Store and Forward(Full Wire Speed)
Switching Capacity	1.6Gbps
Forwarding	0.47Mpps
Rate@64byte
MAC	1K
Buffer Memory	768K
Jumbo Frame	1536bytes
LED Indicator	Power: PWR (Green), Network: Link (Yellow), Fiber port : L/A (Green) , PoE: PoE (Green)
PoE & Power Supply
PoE Port	Port 1-2
Power Supply Pin	Default 1/2 (+), 3/6 (-)
Max Power Per Port	30W; IEEE802.3af/at
Power Consumption	Standby:<3W, Full load:af<30W, at<60W
Working Voltage	48-57VDC; 5 Pin industrial Phoenix terminal, support anti-reverse protection.
Power Supply	No, optional 48V/36W or 48V/60W industrial power supply
Physical Parameter
Operation TEMP / Humidity	-40~+75°C, 5%~90% RH Non condensing
Storage TEMP / Humidity	-40~+85°C, 5%~95% RH Non condensing
Dimension (LWH)	11910030mm
Net /Gross Weight	<0.3kg / <0.6 kg
Installation	Desktop, 35mm DIN rail
Certification & Warranty
Lightning protection	Lightning protection: 6KV 8/20us; Protection level: IP40
	IEC61000-4-2(ESD):±8kV contact discharge,±15kV air discharge
	IEC61000-4-3(RS):10V/m(80~1000MHz)
	IEC61000-4-4(EFT): power cable:±4kV; data cable:±2kV
	IEC61000-4-5(Surge):power cable:CM±4kV/DM±2kV; data cable:±4kV
	IEC61000-4-6(radio frequency transmission):10V(150kHz~80MHz)
	IEC61000-4-8(power frequency magnetic field):100A/m;1000A/m ,1s to 3s
	IEC61000-4-9(pulsed magnet field):1000A/m
	IEC61000-4-10(damped oscillation):30A/m 1MHz
	IEC61000-4-12/18(shockwave):CM 2.5kV,DM 1kV
	IEC61000-4-16(common-mode transmission):30V; 300V,1s
	FCC Part 15/CISPR22(EN55022):Class B
	IEC61000-6-2(Common Industrial Standard)
Mechanical Properties	IEC60068-2-6 (anti vibration), IEC60068-2-27 (anti shock)
Mechanical Properties	IEC60068-2-32 (free fall)
Certification	CCC, CE mark, commercial, CE/LVD EN60950, FCC Part 15 Class B, RoHS
Warranty	5 years, lifelong maintenance.
