Planet IGS-614HPT Endüstriyel PoE Switch

Özellikler

Interface

5 10/100/1000BASE-T Gigabit Ethernet RJ45 copper ports
One SFP slot, supporting 1000BASE-X and 100BASE-FX transceiver in dual modes

Power over Ethernet

Complies with IEEE 802.3at Power over Ethernet Plus, end-span PSE
Backward compatible with IEEE 802.3af Power over Ethernet
Up to 4 ports of IEEE 802.3af/at devices powered
Up to 120-watt PoE budget
Supports PoE power up to 36 watts for each PoE port
Each port supports 54V DC power to PoE powered device
Auto detects powered device (PD)
Circuit protection prevents power interference between ports
Remote power feeding up to 100m

Layer 2 Switching

Features Store-and-Forward mode with wire-speed filtering and forwarding rates
IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
4K MAC address table size
10K jumbo frame
IEEE 802.1Q VLAN transparency
Automatic address learning and address aging
Supports CSMA/CD protocol

Industrial Case and Installation

IP40 metal case
DIN-rail, wall-mount or side wall-mount design
12~56V DC redundant power with reverse polarity protection
Fault alarm for power input failed
Supports 6KV DC Ethernet ESD protection
-40 to 75 degrees C operating temperature
4 real-time PoE power usage indicators

Teknik Özellikler

Hardware Specifications
Copper Ports	5 10/100/1000BASET RJ45 auto-MDI/MDI-X ports
PoE Injector Ports	Four ports with 802.3at PoE+ injector function (Port-1 to Port-4)
SFP Slots	1 1000BASE-SX/LX/BX SFP interface
SFP Slots	Compatible with 100BASE-FX SFP
Connector	Removable 6-pin terminal block
Connector	Pin 1/2 for Power 1; Pin 3/4 for fault alarm; Pin 5/6 for Power 2
Power Requirements	12~56V DC, 7A (max.)
Power Requirements	Redundant power with reverse polarity protection function
Power Consumption	Max. 7.02 watts/24BTU
	(Ethernet Full Loading)
	Max. 132 watts/450BTU
	(Ethernet + PoE Full Loading)
Dimensions (W x D x H)	50 x 87 x 135 mm
Weight	605g
Enclosure	IP40 metal case
Installation	DIN-rail kit and wall-mount kit
ESD Protection	6KV
Switch Specifications
Switch Architecture	Store-and-Forward
Switch Fabric	12Gbps
Throughput (packet per second)	8.93Mpps@64bytes
Address Table	4K entries
Buffer Memory	1M bits on-chip buffer memory
Jumbo Frame	9Kbytes
Flow Control	Back pressure for half duplex
Flow Control	IEEE 802.3x pause frame for full duplex
Power over Ethernet
PoE Standard	IEEE 802.3at Power over Ethernet Plus/PSE
PoE Power Supply Type	End-span
Power Pin Assignment	1/2(+), 3/6(-)
PoE Power Output	Per port 54V DC, max. 36 watts
PoE Power Budget (max.)	60W@12V DC input
	90W@24V DC input
	120W@48V-56V DC input
Max. Number of Class 4 PDs	4
Standards Conformance
Regulatory Compliance	FCC Part 15 Class A, CE
Stability Testing	IEC 60068-2-32 (free fall)
	IEC 60068-2-27 (shock)
	IEC 60068-2-6 (vibration)
Standards Compliance	IEEE 802.3 Ethernet
	IEEE 802.3u Fast Ethernet
	IEEE 802.3ab Gigabit Ethernet
	IEEE 802.3az Gigabit SX/LX
	IEEE 802.3x Full-Duplex Flow Control
	IEEE 802.3az Energy Efficient Ethernet (EEE)
	IEEE 802.3at Power over Ethernet Plus PSE
	IEEE 802.3af Power over Ethernet Plus
	IEEE 802.1p Class of Service
Environment
Temperature	Operating: -40~75 degrees C
Temperature	Storage: -40~75 degrees C
Humidity	Operating: 5~90% (non-condensing)
Humidity	Storage: 5~90% (non-condensing)
Ordering Information
IGS-614HPT	Industrial 4-Port 10/100/1000T 802.3at PoE + 1-Port 10/100/1000T + 1-Port 100/1000XSFP Gigabit Ethernet Switch
