Technology |
Standards | IEEE 802.3af for Power-over-Ethernet |
IEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseT(X) |
Interface | |
RJ45 Ports | 10/100BaseT(X) for PoE IN and DATA OUT |
Power Requirements |
Input Voltage | 48 VDC |
Operating Voltage | 44 to 57 VDC |
Overload Current Protection | 400 mA @ 48 VDC input |
Connection | 1 removable 3-contact terminal block for output |
Output Voltage | 24 VDC |
Output Power | Max. 12.95 watts (0.54 A @ 24 VDC) |
Physical Characteristics |
Housing | Plastic, IP30 protection |
Dimensions | 24.9 × 100 × 86.2 mm (0.98 x 3.93 x 3.39 in) |
Weight | 95 g |
Installation | DIN-rail mounting |
Environmental Limits |
Operating Temperature | Standard Models: 0 to 60°C (32 to 140°F) |
Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
Storage Temperature | -40 to 85°C (-40 to 185°F) |
Ambient Relative Humidity | 5 to 95% (non-condensing) |
Standards and Certifications |
Safety | UL 69050-1 |
EMC | EN 55022 Class A |
EMI | CISPR 22, FCC Part 15B Class A |
EMS | IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV |
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m |
IEC 61000-4-4 EFT: Signal: 2 kV |
IEC 61000-4-5 Surge: Signal: 1 kV |
IEC 61000-4-6 CS: Signal: 10 V |
IEC 61000-4-8 |
Marine | DNV, GL, LR, ABS, NK |
Shock | IEC 60068-2-27 |
Freefall | IEC 60068-2-32 |
Vibration | IEC 60068-2-6 |
Note: Please check Moxa’s website for the most up-to-date certification status. |
MTBF (mean time between failures) |
Time | 5,104,703 hrs |
Standard | MIL-HDBK-217F, GB 25°C |
