Ethernet Connector | 8-Port RJ45 STP with 4-Port "Data" and 4-Port "Data and Power" |
Ethernet Data Rate | 10/100Mbps (vary on Ethernet device attached) |
Input Voltage | DC 48V, 1.5A |
Number of Devices can be Powered | 4 |
Ethernet Cable | TIA/EIA-568, Category 5/5e/6 cable |
LED Indicator | 1 x power, 4 x POE ready / in-use |
Operating Temperature | 0~50 degrees C, 5~90% RH |
Storage Temperature | -20~70 degrees C, 5~90% RH |
Dimension (W x D x H) | 70 x 97 x 26 mm |
Weight | 220g |
Emission | FCC Class A, CE mark |
Standard Compliance | IEEE 802.3 Ethernet |
IEEE 802.3u Fast Ethernet |
IEEE 802.3af Power over Ethernet |
