Cisco SG200 10FP PoE Switch

Teknik Özellikler

Jumbo Frame Support Yes
Minimum Storage Temperature -4 F
Depth 6.7 inches
MTBF 67,009 hour(s)
Height 1.5 inches
Maximum Operating Temperature 104 F
MAC Address Table Size 8000 entries
Localization Chinese (simplified), English, German, French, Italian, Spanish
Width 11 inches
Enclosure Type Rack Mountable
Maxiumum Storage Temperature 158 F
Mounting Kit Included
Ports 8 x 10/100/1000 + 2 x combo Gigabit SFP
Device Type Switch - 10 ports
Remote Management Protocol SNMP, RMON, HTTP, TFTP
Humidity Operating Range 10-90% (non-condensing)
Weight 8.7 lbs
Minimum Operating Temperature 32 F
Interfaces 8 x 10BASE-T/100BASE-TX/1000BASE-T - RJ-45 - PoE | 2 x 10BASE-T/100BASE-TX/1000BASE-T - RJ-45 | 2 x SFP (mini-GBIC)
Humidity Storage Range 10-90% (non-condensing)
Flash Memory 16 MB
Voltage Required AC 120/230 V ( 50/60 Hz )
Performance Switching capacity: 20 Gbps; Forwarding performance (64-byte packet size): 14.88 Mpps
Power Device Power supply - internal
Power Over Ethernet (PoE) PoE
Status Indicators Link activity, port transmission speed, system, PoE
Ram 128 MB
Authentication Method RADIUS
Encryption Algorithm MD5

pdfCisco SG200 10FP PoE Switch Pdf Dosyası706.21 KB

Teknik Kısa

PoE : PoE
Yönetilebilirlik : Yönetilebilir
Aktarım Port Sayısı : 2
Aktarım Türü : Combo
Montaj Tipi : Rack Mount
PoE Port Sayısı : Tooltip 8 Port
PoE Güç Bütçesi : 50-130 Watt
Port Hızı : 1 GBit
