Standard and protocol |
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az, IEEE 802.3at, IEEE 802.3af |
Port |
Sixteen 10/100/1000Mbps adaptive RJ45 ports (Auto MDI/MDIX), two 100/1000Mbps SFP ports |
Network media |
10Base-T: cat3 UTP or above |
100Base-TX: cat5 UTP |
1000Base-T: cat5e UTP |
1000Base-SX:62.5μm/50μm MMF(2m-550m) |
1000Base-LX:62.5μm/50μm MMF (2m-550m) Or 10μm SMF (2m-5000m) |
Transmission mode |
Storage – forwarding |
MAC address capacity |
8K |
Switching capacity |
36Gbps |
Packet forwarding rate |
26.784Mpps |
Package cache |
4.1Mbit |
Jumbo frame |
9216Bytes |
PoE port (RJ45) |
16 port which meet IEEE802.3at/af standard |
Power supply pin |
1/2(+),3/6(-) |
PoE output power |
Max. 240W |
Working mode |
Default mode |
All ports may intercommunicate. |
10M Extend mode |
The speed at ports 1-8 decreases to 10Mbps, the maximum transmission distance is 250m, and all ports may intercommunicate. |
Extend mode |
The speed at ports 1-8 decreases to 10Mbps, the maximum transmission distance is 250m, and all ports may intercommunicate |
