| Donanım Özellikleri |
| Arabirim |
8 PoE+ 10/100/1000Mbps RJ45 Ports |
| 1 10/100/1000Mbps RJ45 Port |
| 1 Gigabit SFP Slot |
| Ağ Medyası |
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
| EIA/TIA-568 100Ω STP (maximum 100m) |
| 100BASE-TX: UTP category 5, 5e cable (maximum 100m) |
| EIA/TIA-568 100Ω STP (maximum 100m) |
| 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) |
| EIA/TIA-568 100Ω STP (maximum 100m) |
| 1000BASE-X MMF, SMF |
| Fan Sayısı |
Fanless |
| Fiziksel Güvenlik Kilidi |
Yes |
| Güç Kaynağı |
External Power Adapter(Output: 53.5VDC / 1.31A) |
| Backup Bandwidth |
20 Gbps |
| Paket Yönlendirme Hızı |
14.88 Mpps |
| PoE+ Portları (RJ45) |
Standard: 802.3at/802.3af compliant |
| PoE Ports: Port1- Port 8 |
| PoE Power Budget: 63W |
| MAC Adres Tablosu |
4K |
| Jumbo Frame |
16 KB |
| Switching Kapasitesi |
20 Gbps |
| Boyutlar ( W X D X H ) |
209 × 126 × 26 mm |
| Maks. Güç Tüketimi |
7.11 W (220/50Hz. no PD connected) |
| 78.13 W (220/50Hz. with 63W PD connected) |
| Max Heat Dissipation |
24.25 BTU/h (no PD connected) |
| |
266.42 BTU/h (with 63W PD connected) |
| Yazılım Özellikleri |
| Gelişmiş Özellikler |
Compatible With IEEE 802.3af/at Compliant PDs |
| EEE802.3x Flow Control |
| 802.1p/DSCP QoS |
| IGMP Snooping |
| İletim Metodu |
Store-And-Forward |
| Diğerleri |
| Sertifika |
CE, FCC, RoHS |
| Paket İçeriği |
TL-SG1210P, Power Adapter, Installation Guide |
| Ortam |
Operating Temperature: 0°C~40°C (32°F~104°F) |
| Storage Temperature: -40°C~70°C (-40°F~158°F) |
| Operating Humidity: 10% ~ 90% non-condensing |
| Storage Humidity: 5%~90% non-condensing |
