Donanım Özellikleri |
Arabirim | • 16× PoE+ 10/100 Mbps RJ45 Ports |
• 2× 10/100/1000 Mbps RJ45 Ports |
• 1× Combo Gigabit SFP Slot |
Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
• EIA/TIA-568 100Ω STP (maximum 100m) |
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m) |
• EIA/TIA-568 100Ω STP (maximum 100m) |
• 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) |
• EIA/TIA-568 100Ω STP (maximum 100m) |
• 1000BASE-X MMF, SMF |
Fan Sayısı | 2 Fans |
Fiziksel Güvenlik Kilidi | Yes |
Güç Kaynağı | 100–240V AC, 50/60 Hz |
PoE+ Portları (RJ45) | • Standard: 802.3at/802.3af compliant |
• PoE Ports: Ports 1–16 |
• PoE Power Budget: 150 W |
Boyutlar ( W X D X H ) | 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm) |
Maks. Güç Tüketimi | • 12.71 W (220/50Hz. no PD connected) |
• 172.8 W (220/50Hz. with 150 W PD connected) |
Max Heat Dissipation | • 43.34 BTU/h (no PD connected) |
• 589.25 BTU/h (with 150 W PD connected) |
Performans |
Anahtarlama Kapasitesi | 7.2 Gbps |
Paket Yönlendirme Hızı | 5.36 Mpps |
MAC Adres Tablosu | 8K |
Jumbo Frame | 10 KB |
Yazılım Özellikleri |
Gelişmiş Özellikler | • Compatible With IEEE 802.3at/af Compliant PDs |
• Extend Mode (Up to 250m PoE power supply and data transmission) |
• Priority Mode |
• Isolation Mode |
• Mac Address Auto-Learning And Auto-Aging |
• IEEE802.3x Flow Control |
İletim Metodu | Store-And-Forward |
Diğerleri |
Sertifika | CE, FCC, RoHS |
Paket İçeriği | • TL-SL1218P |
• Power Cable |
• Installation Guide |
• Two mounting brackets and the fittings |
Ortam | • Operating Temperature: 0–50 °C (32–122 °F) |
• Storage Temperature: -40–70 °C (-40–158 °F) |
• Operating Humidity: 10–90% RH non-condensing |
• Storage Humidity: 5–90% RH non-condensing |
