Planet FGSW-2022VHP Fast Ethernet PoE Switch
Özellikler
| Hardware Specifications | |
| Copper Ports | 16 10/100BASE-TX RJ45 auto-MDI/MDI-X ports with port-1 to port-16 |
| 2 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports with port-17 to port-18 | |
| SFP/mini-GBIC Slots | 2 1000BASE-X SFP interfaces with port-19 to port-20 |
| PoE Injector Ports | 4 ports with 802.3bt PoE++ injector function with port-1 to port-4 |
| 12 ports with 802.3at PoE+ injector function with port-5 to port-16 | |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 11.2Gbps/non-blocking |
| Throughput (packet per second) | 8.3Mpps@64 bytes packet |
| MAC Address Table | 8K entries |
| Jumbo Frame | 9K bytes |
| Flow Control | IEEE 802.3x pause frame for full duplex; back pressure for half duplex |
| LED Indicators | System: |
| Power (Green) | |
| 10/100BASE-TX RJ45 Interfaces: | |
| 10/100Mbps LNK/ACT (Green) | |
| PoE-in-Use (Amber) | |
| 1000BASE-X SFP Interfaces: | |
| LNK/ACT (Green) | |
| 1000Mbps (Green) | |
| 10/100/1000BASE-T TP Interfaces: | |
| LNK/ACT (Green) | |
| 100Mbps (Red) | |
| 1000Mbps (Green) | |
| LCD Monitor (W x D) | 40.6 x 30.5 mm, 2-inch |
| Buttons | Menu, Enter, Back, Up and Down |
| Dimensions (W x D x H) | 233 x 440 x 44 mm (1U height) |
| Enclosure | Metal |
| Weight | 3.3kg |
| Power Requirements | 100~240V AC, 50/60Hz, 5A max. |
| Power Consumption/ Dissipation | Max. 330watts/1132 BTU |
| Thermal Fan | 3 |
| ESD Protection | Contact discharge of ±6KV DC |
| Air discharge of ±8KV DC | |
| Surge Protection | ±6KV |
| Power over Ethernet | |
| PoE Standard | IEEE 802.3bt PoE++ PSE (Port 1-4) |
| IEEE 802.3af/at PoE+ PSE (Port 5-16) | |
| PoE Power Supply Type | 802.3bt/UPoE/Legacy (Port 1-4) |
| End-span (Port 5-16) | |
| PoE Power Output | Per PoE++ port 54V DC, 1.2A. max. 60 watts |
| Per PoE+ port 54V DC, 600mA. max. 32 watts | |
| Power Pin Assignment | 802.3bt: 1/2 (+), 3/6 (-), 4/5 (+), 7/8 (-) |
| End-span: 1/2 (-), 3/6 (+) | |
| PoE Power Budget | 300 watts |
| Max. Number of Class 2 PDs | 16 |
| Max. Number of Class 3 PDs | 16 |
| Max. Number of Class 4 PDs | 11 |
| Standards Conformance | |
| Regulatory Compliance | FCC Part 15 Class A, CE |
| Standards Compliance | IEEE 802.3 10BASE-T |
| IEEE 802.3u 100BASE-TX | |
| IEEE 802.3ab Gigabit 1000BASE-T | |
| IEEE 802.3z Gigabit SX/LX | |
| IEEE 802.3x Flow Control and Back Pressure | |
| IEEE 802.3af Power over Ethernet | |
| IEEE 802.3at Power over Ethernet Plus | |
| IEEE 802.3bt PoE++ (Type 3) | |
| IEEE 802.3az Energy Efficient Ethernet (EEE) | |
| Environment | |
| Operating | Temperature: -10 ~ 60 degrees C |
| Relative Humidity: 5 ~ 90% (non-condensing) | |
| Storage | Temperature: -15 ~ 70 degrees C |
| Relative Humidity: 5 ~ 90% (non-condensing) | |
Planet FGSW-2022VHP Fast Ethernet PoE Switch Pdf Dosyası1.26 MB
Teknik Kısa
PoE : PoE Plus
Port Hızı : 100 Mbps
Yönetilebilirlik : Yönetilemez
Aktarım Port Sayısı : 2
Aktarım Türü : Gbit Fiber
PoE Port Sayısı :
16 Port
16 Port PoE Güç Bütçesi : 200-400 Watt
