D-Link DGS1100 24P ME PoE Switch
Teknik Özellikler
| Fiziksel Özellikler |
| Number of Ports |
| • 24 10/100/1000BASE-TX ports (PoE) |
| Standards |
| • IEEE 802.3 compliance |
| • IEEE 802.3u compliance |
| • IEEE 802.3ab compliance |
| • IEEE 802.3x Flow Control |
| • IEEE 802.3az compliance |
| • IEEE 802.3af compliance |
| Performance |
| Switching Capacity |
| • 48 Gbps |
| 64-byte Maximum Forwarding Rate |
| • 35.71 Mbps (based on 64 Bytes) |
| MAC Address Table Size |
| • 8K Entries |
| DRAM for CPU |
| • 128 MB |
| Packet Buffer |
| • 4.1 Mbit |
| Flash Memory |
| • 16 MB |
| Jumbo Frame |
| • Up to 10 Kbytes |
| LEDs |
| • Power (per device) |
| • Link/Activity/Speed (per port) |
| Power Consumption |
| Standby Mode |
| • 3.4 watts |
| Maximum |
| • 7.9 watts |
| Software Features |
| L2 Features |
| • MAC Address Table: 8K |
| • 802.3x Flow Control |
| • HOL Blocking Prevention |
| • Loopback Detection |
| • Port Mirroring |
| • Max 4 Mirror sessions |
| • One-to-One |
| • Many-to-One |
| L2 Multicasting |
| • IGMP Snooping |
| • IGMP Snooping v1/v2, v3 Awareness |
| • Supports 256 IGMP snooping groups (shared with MLD Snooping) |
| • Host-based IGMP snooping Fast Leave |
| • IGMP Authentication |
| • MLD Snooping |
| • MLD Snooping v1, v2 |
| • Supports 256 MLD snooping groups (shared with IGMP Snooping) |
| • Host-based MLD Snooping Fast Leave |
| • Limited IP Multicast |
| VLAN |
| • 802.1Q Tagged VLAN |
| • VLAN Group |
| • Supports 32 static VLAN groups |
| • Management VLAN |
| • Port-based VLAN |
| • ISM VLAN |
| • Double VLAN (Q-in-Q) |
| • Port-based Q-in-Q |
| Quality of Service (QoS) |
| • 8 queues per port |
| • Queue Handling |
| • Strict Priority |
| • Weighted Round Robin (WRR) |
| • Bandwidth Control |
| • Port-based (Ingress/Egress, min. granularity 16 Kb/s) |
| • CoS Based on: |
| • 802.1p |
| • DSCP |
| Security |
| • Port Security |
| • Up to 64 MAC addresses per port |
| • Traffic Segmentation |
| • Broadcast/Multicast/Unknown Unicast Storm Control |
| • D-Link Safeguard Engine |
| AAA |
| • 802.1X |
| • Port-based Access Control |
| • Host-based Access Control |
| • Supports Guest VLAN |
| • Support Local/RADIUS Servers |
| • Support RADIUS Accounting |
| • 3 Levels of User Accounts |
| OAM |
| • Cable Diagnostics |
| • 802.3ah |
| Management |
| • Web-based GUI |
| • Command Line Interface (CLI) |
| • Telnet Server |
| • TFTP Client |
| • SNMP v1/v2c/v3 |
| • SNMP Traps |
| • System Log |
| • RMON v1 |
| • Support 1,2,3,9 Groups |
| • LLDP |
| • DHCP Client |
| • DHCP Auto-Configuration |
| • DHCP Relay for IPv4/IPv6 |
| • DHCP Relay Option 82 |
| • DHCP Relay Option 37 |
| • PPPoE Circult-ID Tag Insertion |
| • SNTP |
| • CPU Monitoring |
| • Password Encryption |
| MIB |
| • RFC1213 MIB II |
| • RFC1493 Bridge MIB |
| • RFC1907 SNMPv2 MIB |
| • RFC1398, 1643, 1650, 2358, 2665 Ether-like MIB |
| • RFC 2233, 2863 IF MIB |
| • RFC 2618 RADIUS Authentication Client MIB |
| • RFC2620 RADIUS Accounting Client MIB |
| • Private MIB |
| IETF Standard |
| • RFC768 UDP |
| • RFC791 IP |
| • RFC792,2463, 4443 ICMPv4 |
| • RFC793 TCP |
| • RFC826 ARP |
| • RFC 2474, 3260 Definition of the DS Field in the IPv4 and IPv6 Header |
| • RFC 1321, 2284, 2865, 3580, 3748 Extensible Authentication Protocol (EAP) |
| • RFC2571, RFC2572, RFC2573, RFC2574 SNMP |
| • RFC1981, RFC2460, RFC2461,4861, RFC2462,4862, RFC2464, RFC3513,4291, RFC2893,4213 |
| Physical & Enviromental |
| Power Input |
| • External Power Adapter: 100 to 240 V AC, 50 to 60 Hz |
| • Output: 12 V/1 A |
| Size |
| • 190 x 120 x 38 mm (7.48 x 4.72 x 1.50 inches) |
| MTBF |
| • 706,061 hours |
| Acoustics |
| • 0 dB |
| Heat Dissipation |
| • 26.97 BTU/hr |
| Weight |
| • 0.63 kg |
| Ventilation |
| • Fanless |
| Operating Temperature |
| • -5 to 50 °C (23 to 122 °F) |
| Storage Temperature |
| • -40 to 70 °C (-40 to 158 °F) |
| Operating Humidity |
| • 10% to 90% |
| • EMI CE Class B, FCC Class B, VCCI, BSMI |
| • Safety CE LVD, UL/cUL, CB, BSMI |
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 2
PoE Güç Bütçesi : 50-130 Watt
PoE Port Sayısı :
1 Port
1 Port 24 Port
