| Standartlar | Ethernet:IEEE802.310BaseT,IEEE 802.3u 100BaseTX,IEEE |
| 802.ab 1000BaseT,IEEE802.3z 1000BaseSX/LX IEEE 802.3x Flow Control |
| IEEE 802.3ad Link Aggregation ControlProtocol |
| IEEE 802.1Q VLAN |
| IEEE 802.1p Class of Service |
| IEEE 802.1D Spanning TreeProtocol |
| IEEE 802.1w Rapid Spanning TreeProtocol |
| IEEE 802.3at Power Over Ethernet(PoE+) |
| Özellikler | Numberof Ports:26 |
| 10/100BaseTX withRJ-45Connectors:24port with PoE+ GigabitUplink:2x 10/100/1000BaseTRJ-45/Gigabit SFP ComboPort |
| MAC Address:4K |
| Buffer Memory:2.75Mb |
| TransmissionMethod:StoreandForward |
| Akıllı Özellikler | Port Based VLAN:26 |
| TaggedBasedVLAN:32,VID=1~4094 |
| STP/RSTP |
| IGMPSnoopingV1&V2 |
| Link Aggregation:3groups |
| Quality ofService(QoS):High& Low queues,802.1p |
| Security:Port&MAC binding,3MAC perport Port:Port State,Speed/Duplex,Flow Control Port Mirroring |
| BandwidthControl |
| BroadcastStorm Control |
| PoEControl:PoEPortEnable/Disable, PoEStatus |
| Management:Web Management,password protected access, |
| Configuration backup/restore,TFTPfirmwareupgrade |
| Filtreleme / İletim Hızı | 1000Mbpsport – 1,488,000pps, |
| 100Mbpsport -148,800pps,10Mbpsport -14,880pps |
| Medya İletimi | 10/100BaseTX Cat. 5UTP/STP |
| 1000BaseT Cat. 5/ Cat. 5EUTP/STP |
| LED Indikatör | PerPort:Link/Act,PoE:Act/ Status,PerUnit:Power |
| Güç Girişi | 100~240V/AC,50~60Hz |
| Güç Çıkışı | 53VDC PerPort Output |
| Güç Tüketimi | 400Watt (Max. ) |
| Boyutlar | 44×440×332mm(H xWx D) |
| Çalışma Sıcaklığı | 0to40℃ |
| Depolama Sıcaklığı | -20to90℃ |
| Nem | 10to90% RH (non-condensing) |
| Sertifika | FCC ClassA,CE |
| Ağırlık | 4.7kg |
