Planet FGSW 2511P PoE Switch

Özellikler

Physical Interface

24 10/100BASE-TX RJ45 copper ports
One 10/100/1000BASE-T Gigabit RJ45 copper port
One shared 1000BASE-X SFP interface
Hardware-based DIP switch for “Standard”, “VLAN”, “QoS” or “Extend” mode selection

Power over Ethernet

Complies with IEEE 802.3at Power over Ethernet Plus mid-span PSE
Up to 24 IEEE 802.3af/at devices powered
Supports PoE power up to 30 watts for each PoE port
190-watt PoE budget
Each PoE port supports 52V DC power to PoE powered device
Auto detects powered device (PD)
Circuit protection prevents power interference between ports
Remote power feeding up to 100m in standard mode
The “Extend” mode features 25-watt PoE transmit distance of 250m at speed of 10Mbps

Switching

Hardware-based 10/100Mbps and 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
Flow control for full duplex operation and back pressure for half duplex operation
Integrates address look-up engine, supporting 16K absolute MAC addresses
Automatic address learning and address aging
Solid DIP switch to isolate ports to prevent broadcast storm and defend DHCP spoofing

Hardware

19-inch rack-mount size, 1U height
LED indicators for PoE ready/activity and LINK/ACT
Internal AC power supply
Supports Energy-Efficient Ethernet (EEE) function (IEEE 802.3az)

Teknik Özellikler

Hardware Specifications
10/100Mbps Ports	24 10/100BASE-TX MDI/MDI-X RJ45 ports
Gigabit Ports	1 10/100/1000BASE-T MDI/MDI-X RJ45 port
SFP Slot	1 1000BASE-X SFP interface, shared with Gigabit RJ45 copper
PoE Inject Port	24-port with 802.3at PoE injector function (Port-1 to Port-24)
LED Display	System:
	Power (Green)
	10/100BASE-TX RJ45 Interface:
	LNK/ACT (Green, Port-1 to Port-24)
	PoE (Amber, Port-1 to Port-24)
	10/100/1000BASE-T RJ45 and 1000BASE-X combo Interface:
	LNK/ACT (Green, Port 25)
DIP Switch	4 operation modes:
DIP Switch	Standard/QoS/VLAN/Extend
Switch Architecture	Store and Forward
MAC Address Table	16K MAC address table with auto learning function
Switch Fabric	6.8Gbps
Switch Throughput	5.06Mpps @64bytes
Maximum Packet Size	16K bytes
Flow Control	Back pressure for half duplex
Flow Control	IEEE 802.3x pause frame for full duplex
Power Requirements	AC 100~240V, 3A max.
Power Consumption	205 watts, 699.5 BTU
Dimensions (W x D x H)	440 x 200 x 45 mm
Weight	2419 g
ESD Protection	Contact discharge of ±6KV DC
ESD Protection	Air discharge of ±8KV DC
Surge Immunity	±4KV
Power over Ethernet
PoE Standard	IEEE 802.3at Power over Ethernet Plus/PSE
PoE Power Supply Type	Mid-span
Power Pin Assignment	4/5 (+), 7/8(-)
PoE Power Output	Per Port 52V DC, 600mA. max. 30 watts (IEEE 802.3at)
PoE Power Output	Per Port 52V DC, 300mA. max. 15.4 watts (IEEE 802.3af)
PoE Power Budget	190 watts
Number of PDs, 7 watts	24
Number of PDs, 15 watts	12
Number of PDs, 30 watts	6
Standard Conformance
EMI Safety	CE, FCC
Standard Compliance	IEEE 802.3 Ethernet
	IEEE 802.3u Fast Ethernet
	IEEE 802.3ab Gigabit 1000BASE-T
	IEEE 802.3z Gigabit SX/LX
	IEEE 802.3x Flow Control
	IEEE 802.3af Power over Ethernet
	IEEE 802.3at Power over Ethernet Plus
	IEEE 802.3z Energy Efficient Ethernet
Environment
Operating Environment	0 ~ 50 degrees C
Storage Environment	-10 ~ 70 degrees C
Operating Humidity	5 ~ 95%, relative humidity, non-condensing
Storage Humidity	5 ~ 95%, relative humidity, non-condensing
