Planet GSW 2400HPS PoE Switch
Teknik Özellikler
Donanım Özellikleri | |
Bakır Portlar | 24 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X Ports |
PoE Injector Port | 24 802.3af / 802.3at PoE Injector Ports |
LED Indicators | System: |
Power (Green) | |
PoE Ethernet Interfaces: | |
PoE In-Use (Orange) | |
1000 LNK / ACT (Green), 10/100 LNK / ACT (Orange) | |
Switch Processing Scheme | Store-and-Forward |
MAC Adres Tablosu | 8K entries |
Switch Fabric | 48Gbps / non-blocking |
Throughput @ 64Kbytes | 35.7Mpps |
Data Aktarım Hızı | 3.5Mbit SRAM Packet Buffer |
Akış Kontrolü | IEEE 802.3x Pause Frame for Full-Duplex. |
Back pressure for Half-Duplex | |
Jumbo Frame | 9216 Bytes |
Güç Tüketimi | Max. 330 watts / 1122 BTU |
Güç Gereksinimi | AC 100~240V, 50/60Hz, 4A max. |
Ölçüler (W x D x H) | 445 x 207 x 45 mm (1U height) |
Ağırlık | 2.76kg |
Power over Ethernet | |
PoE Standart | IEEE 802.3af Power over Ethernet / PSE |
IEEE 802.3at Power over Ethernet Plus / PSE | |
PoE Power Output | Per Port 52V DC, 300mA. Max. 15.4 watts (IEEE 802.3af) |
Per Port 52V DC, 600mA. Max. 30 watts (IEEE 802.3at) | |
PoE Power Budget | 300 watts |
Number of PDs, 7 watts | 24 |
Number of PDs, 15.4 watts | 19 |
Number of PDs, 30.8 watts | 9 |
Layer 2 Fonksiyonu | |
Yönetim Arayüzü | IPv4 Web Browser |
Port Konfigürasyonu | Port disable / enable |
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection | |
Flow Control disable / enable | |
Display each port’s state, speed duplex mode, flow control status | |
Port Statistics | Display each port’s state, link status, packet transmit / receive counter |
VLAN | 802.1Q Tagged Based VLAN |
Up to 32 VLAN groups, out of 4094 VLAN IDs | |
QoS | 4 priority queues on all switch ports |
Traffic classification based, Strict priority and Weight Fair Queue / Weighted Round Robin (WRR) policies | |
- Port-based priority | |
Trunk | Static Trunk |
Features 8 groups of 4-port trunk support | |
Port Mirroring | Port mirroring allows monitoring of the traffic across any port in real time |
Port Isolation | Yes |
Band Genişliği | Ingress / Egress Rate Limit per port |
Storm Control | Broadcast / Multicast / Unknown-Unicast / Unknown-Multicast |
Jumbo Frame | 1522 / 1536 / 1552 / 9216bytes Jumbo packet setting |
Loop Protection | Loop Prevention / Detection |
Green Networking | Enable / Disable |
Güvenlik | MAC Security |
- MAC Forwarding Table | |
- Static MAC | |
MAC Constrain | |
Cable Diagnostics | Support |
Konfigürasyon Yönetimi | Configuration backup / restore through Web interface |
Firmware Upgrade | Web interface |
Standart Uygunluğu | |
Yönetmelik Uygunluğu | FCC Part 15 Class A, CE |
Standart Uygunluğu | IEEE 802.3 10Base-T |
IEEE 802.3u 100Base-TX | |
IEEE 802.3ab 1000Base-T | |
IEEE 802.3x Flow Control | |
IEEE 802.1p QoS | |
IEEE 802.1Q VLAN Tagging | |
IEEE 802.3af Power over Ethernet | |
IEEE 802.3at High Power over Ethernet |
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 2
PoE Güç Bütçesi : 200-400 Watt
PoE Port Sayısı : 24 Port
