Moxa TN 4528A 16PoE 2GPoE 2GODC WV T PoE Switch

Teknik Özellikler

Input/Output Interface	Alarm Contact Channels	2 x relay output in one M12 A-coded 5-pin male connector with current carrying capacity of 1 A @ 30 VDC
Ethernet Interface	10/100BaseT(X) Ports (M12 D-coded 4-pin female connector)	8
	PoE Ports (10/100BaseT(X), M12 D-coded 4-pin female connector)	16
	PoE Ports (100/1000BaseT(X), M12 X-coded 8-pin female connector)	2
	PoE Ports (100/1000BaseT(X), M12 X-coded 8-pin female connector)	2
	10/100/1000BaseT(X) Ports, Q-ODC Fiber Connector	2
	Standards	IEEE 802.1D-2004 for Spanning Tree Protocol
		IEEE 802.1p for Class of Service
		IEEE 802.1Q for VLAN Tagging
		IEEE 802.1s for Multiple Spanning Tree Protocol
		IEEE 802.1w for Rapid Spanning Tree Protocol
		IEEE 802.1X for authentication
		IEEE 802.3 for 10BaseT
		IEEE 802.3ab for 1000BaseT(X)
		IEEE 802.3ad for Port Trunk with LACP
		IEEE 802.3af/at for PoE/PoE+ output
		IEEE 802.3u for 100BaseT(X) and 100BaseFX
		IEEE 802.3x for flow control
		IEEE 802.3z for 1000BaseSX/LX/LHX/ZX
Ethernet Software Features	Broadcast Forwarding	IP directed broadcast, broadcast forwarding
	Configuration Options	Command Line Interface (CLI), Command Line Interface (CLI) through Serial/Telnet/SSH, Web Console (HTTP/HTTPS), Windows Utility
	Filter	802.1Q, GMRP, GVRP, IGMP v1/v2/v3, Port-based VLAN, Static Multicast
	Industrial Protocols	EtherNet/IP Adapter (Slave), Modbus TCP Server (Slave)
	Management	Back Pressure Flow Control, DHCP Option 66/67/82, DHCP Server/Client, Flow control, HTTP, IPv4/IPv6, LLDP, Port Mirror, QoS/CoS/ToS, RARP, RMON, SMTP, SNMP Inform, SNMP Trap, Syslog, Telnet, Account Management
	MIB	Bridge MIB, Ethernet-like MIB, MIB-II, P-BRIDGE MIB, Q-BRIDGE MIB, RMON MIB Groups 1, 2, 3, 9, RSTP MIB
	Redundancy Protocols	Link Aggregation, MSTP, RSTP, STP, Turbo Chain, Turbo Ring v1/v2, Turbo Ring with DRC
	Security	Broadcast storm protection, HTTPS/SSL, Local Account Accessibility, TACACS+, Port Lock, RADIUS, Rate Limit, SSH
	Time Management	IEEE 1588 PTP v1/v2, NTP Server/Client, SNTP
Switch Properties	IGMP Groups	256
	Max. No. of VLANs	64
	VLAN ID Range	VID 1 to 4094
LED Interface	LED Indicators	STATE, PWR1, PWR2, FAULT, 10/100/1000M
Serial Interface	Console Port	M12 A-coded male connector
Power Parameters	Input Current	7.2 mA @ 24 VDC
	Input Voltage	24/36/48/72/96/110 VDC
	No. of Power Inputs	2
	Operating Voltage	16.8 to 137.5 VDC
	Overload Current Protection	Supported
	Power Connector	M23 connector
	Reverse Polarity Protection	Supported
	Total PoE Power Budget	120 W
Physical Characteristics	Housing	Metal
	IP Rating	IP42
	Dimensions	347.8 x 132 x 122.3 mm (13.70 x 5.20 x 4.81 in)
	Weight	3375 g (7.44 lb)
	Installation	DIN-rail mounting (optional), Wall mounting
Environmental Limits	EMC	EN 55032/24
	EMS	IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
		IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
		IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
		IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
		IEC 61000-4-6 CS: 10 V
		IEC 61000-4-8 PFMF
	Freefall	IEC 60068-2-31
	Radio Frequency	FCC
	Railway	EN 50121-4, EN 50155, IEC 60571
	Railway Fire Protection	EN 45545-2
	Safety	IEC 60950-1, UL 61010-2-201
	Shock	IEC 60068-2-27, IEC 61373, EN 50155
	Vibration	IEC 60068-2-64, IEC 61373, EN 50155
Declaration	Green Product	RoHS, CRoHS, WEEE
MTBF	Standards	Telcordia SR332
	Time	387,767 hrs
	Warranty Period	5 years
