Planet GS-5220-24PL4XR Layer 3 PoE Switch
Teknik Özellikler
Hardware Specifications | |
Hardware Version | 2 |
Copper Ports | 24 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports |
SFP/mini-GBIC Slots | 4 100/1000BASE-X SFP interfaces, shared with Port-21 to Port-24 |
Compatible with 100BASE-FX SFP transceiver | |
SFP+ Slots | 4 10GBASE-SR/LR SFP+ interfaces (Port-25 to Port-28) |
Console | 1 x RS232-to-RJ45 serial port (115200, 8, N, 1) |
SDRAM | 512MBytes |
Flash Memory | 64Mbytes |
Reset Button | < 5 sec: System reboot |
> 5 sec: Factory default | |
Dimensions (W x D x H) | 440 x 300 x 44.5 mm, 1U height |
Weight | GS-5220-24P4X: 4546g |
GS-5220-24PL4XR: 5071g | |
Power Consumption | GS-5220-24P4X: Max. 452watts/1550.8BTU |
GS-5220-24PL4XR: AC: Max. 661.5 watts/2268.2 BTU, DC: Max. 34.5 watts/118.4 BTU | |
Power Requirements – AC | GS-5220-24P4X: AC 100~240V, 50/60Hz, 8A |
GS-5220-24PL4XR: AC 100~240V, 50/60Hz, 10A | |
Power Requirements – DC | GS-5220-24PL4XR: DC 36~60V, 2A |
ESD Protection | 6KV DC |
Fan | 3 smart fans |
LED | System: |
SYS (Green) | |
AC/PWR (Green) | |
DC (Green) (GS-5220-24PL4XR Only) | |
Ring (Green) | |
Fan1/2/3 Alert (Red) | |
PoE PWR Alert (Red) | |
PoE Ethernet Interfaces (Port-1 to Port-24): | |
PoE (Orange) | |
Ethernet Interfaces (Port-1 to Port-24): | |
1000 LNK/ACT (Green), 10/100 LNK/ACT (Orange) | |
100/1000Mbps SFP Combo Interfaces (Port 21 to Port 24): | |
1000 (Green), 100 (Orange) | |
1/10G SFP+ Interfaces (Port-25 to Port-28) : | |
1G (Green), 10G (Orange) | |
Switching Specifications | |
Switch Architecture | Store-and-Forward |
Switch Fabric | 128Gbps/non-blocking |
Throughput | 95.23Mpps@64Bytes |
Address Table | 16K entries, automatic source address learning and aging |
Shared Data Buffer | 32M bits |
Flow Control | IEEE 802.3x pause frame for full duplex |
Back pressure for half duplex | |
Jumbo Frame | 10K bytes |
Power over Ethernet | |
PoE Standard | IEEE 802.3at PoE+ PSE |
PoE Power Supply Type | End-span |
PoE Power Output | 36 watts (max.) |
Power Pin Assignment | End-span : 1/2(-), 3/6(+) |
PoE Power Budget | GS-5220-24P4X: 400 watts (max.) |
GS-5220-24PL4XR: 600 watts (max.) | |
PoE Ability PD @ 7 watts | GS-5220-24P4X: 24 units |
GS-5220-24PL4XR: 24 units | |
PoE Ability PD @ 15.4 watts | GS-5220-24P4X: 24 units |
GS-5220-24PL4XR: 24 units | |
PoE Ability PD @ 30.8 watts | GS-5220-24P4X: 12 units |
GS-5220-24PL4XR: 20 units | |
Layer 3 Functions | |
IP Interfaces | Max. 128 VLAN interfaces |
Routing Table | Max. 128 routing entries |
Routing Protocols | Ipv4 OSPFv2 |
Ipv4 hardware static routing | |
Ipv6 hardware static routing | |
Layer 2 Management Functions | |
Port Configuration | Port disable/enable |
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection | |
Flow control disable/enable | |
Port Status | Display each port’s speed duplex mode, link status, flow control status, |
auto-negotiation status, trunk status | |
Port Mirroring | TX/RX/Both |
Many-to-1 monitor | |
VLAN | IEEE 802.1Q tagged based VLAN |
IEEE 802.1ad Q-in-Q tunneling | |
Private VLAN Edge (PVE) | |
MAC-based VLAN | |
Protocol-based VLAN | |
Voice VLAN | |
MVR (Multicast VLAN registration) | |
Up to 4K VLAN groups, out of 4095 VLAN IDs | |
Link Aggregation | IEEE 802.3ad LACP/static trunk |
14 groups with 8 port per trunk | |
Spanning Tree Protocol | IEEE 802.1D Spanning Tree Protocol (STP) |
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) | |
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) | |
IGMP Snooping | IPv4 IGMP (v1/v2/v3) snooping |
IPv4 IGMP querier mode support | |
Up to 255 multicast groups | |
MLD Snooping | MLD (v1/v2) snooping |
MLD querier mode support | |
Up to 255 multicast groups | |
Bandwidth Control | Per port bandwidth control |
Ingress: 100Kbps~1000Mbps | |
Egress: 100Kbps~1000Mbps | |
QoS | Traffic classification based, strict priority and WRR |
8-level priority for switching: | |
- Port number | |
- 802.1p priority | |
- 802.1Q VLAN tag | |
- DSCP/ToS field in IP packet | |
Ring | Supports ERPS, and complies with ITU-T G.8032 |
Recovery time < 10ms@ 3 units | |
Recovery time < 50ms@16 units | |
Security Functions | |
Access Control List | IP-based ACL/MAC-based ACL |
ACL based on: | |
- MAC Address | |
- IP Address | |
- Ethertype | |
- Protocol Type | |
- VLAN ID | |
- DSCP | |
- 802.1p Priority | |
Up to 256 entries | |
Security | Port security |
IP source guard | |
Dynamic ARP inspection | |
Command line authority control based on user level | |
AAA | RADIUS client |
TACACS+ client | |
Network Access Control | IEEE 802.1x port-based network access control |
MAC-based authentication | |
Local/RADIUS authentication | |
Switch Management | |
Basic Management Interfaces | Console |
Telnet | |
Web browser | |
SNMP v1, v2c | |
Secure Management Interfaces | SSHv2 |
TLSv1.2 | |
SNMP v3 | |
System Management | Configuration upload/download through HTTP |
Remote Syslog | |
System log | |
LLDP protocol | |
NTP | |
PLANET Smart Discovery Utility | |
SNMP MIBs | RFC 1213 MIB-II |
RFC 1493 Bridge MIB | |
RFC 1643 Ethernet MIB | |
RFC 2863 Interface MIB | |
RFC 2665 Ether-Like MIB | |
RFC 2819 RMON MIB (Groups 1, 2, 3 and 9) | |
RFC 2737 Entity MIB | |
RFC 2618 RADIUS Client MIB | |
RFC 2863 IF-MIB | |
RFC 2933 IGMP-STD-MIB | |
RFC 3411 SNMP-Frameworks-MIB | |
RFC 4292 IP Forward MIB | |
RFC 4293 IP MIB | |
RFC 4836 MAU-MIB | |
IEEE 802.1X PAE | |
LLDP | |
Standards Conformance | |
Regulatory Compliance | FCC Part 15 Class A, CE |
Standards Compliance | IEEE 802.3 10BASE-T |
IEEE 802.3u 100BASE-TX/100BASE-FX | |
IEEE 802.3z Gigabit SX/LX | |
IEEE 802.3ab Gigabit 1000T | |
IEEE 802.3ae 10Gb/s Ethernet | |
IEEE 802.3x flow control and back pressure | |
IEEE 802.3ad port trunk with LACP | |
IEEE 802.1D Spanning Tree Protocol | |
IEEE 802.1w Rapid Spanning Tree Protocol | |
IEEE 802.1s Multiple Spanning Tree Protocol | |
IEEE 802.1p Class of Service | |
IEEE 802.1Q VLAN tagging | |
IEEE 802.1x Port Authentication Network Control | |
IEEE 802.1ab LLDP | |
IEEE 802.3af Power over Ethernet | |
IEEE 802.3at Power over Ethernet Plus | |
RFC 768 UDP | |
RFC 793 TFTP | |
RFC 791 IP | |
RFC 792 ICMP | |
RFC 2068 HTTP | |
RFC 1112 IGMP v1 | |
RFC 2236 IGMP v2 | |
RFC 3376 IGMP v3 | |
RFC 2710 MLD v1 | |
RFC 3810 MLD v2 | |
RFC 2328 OSPF v2 | |
ITU-T G.8032 ERPS Ring | |
Environment | |
Operating | Temperature: 0 ~ 50 degrees C |
Relative Humidity: 5 ~ 95% (non-condensing) | |
Storage | Temperature: -10 ~ 70 degrees C |
Relative Humidity: 5 ~ 95% (non-condensing) |
Planet GS-5220-24PL4XR Layer 3 PoE Switch Pdf Dosyası3.78 MB
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 3
Aktarım Port Sayısı : 4
Aktarım Türü : Gbit Fiber
Montaj Tipi : Rack Mount
PoE Port Sayısı : 24 Port
