Planet GSW-2824P Gigabit PoE Switch
Teknik Özellikler
Hardware Specifications | |
10/100/1000BASE-T Copper Ports | 28 auto MDI/MDIX |
1000BASE-X SFP/mini-GBIC Slots | 2 |
DIP Switch | Selectable operation mode |
- Standard | |
- VLAN | |
- Extend | |
Dimensions (W x D x H) | 441.5 x 207.3 x 44 mm (1U height) |
Enclosure | Metal |
Weight | 3022g |
Power Requirements | 100~240V AC, 50/60Hz, 5A max. |
Power Consumption/Dissipation | Max. 278 watts/948 BTU |
Thermal Fan | 2 |
ESD Protection | Contact discharge of ±6KV DC, |
Air discharge of ±8KV DC | |
Surge Protection | ±6KV |
Installation | Desktop or rack-mount installation |
LED Indicators | System |
Power (Green) | |
10/100/1000T RJ45 Interfaces | |
10/100 LNK / ACT(Amber) | |
1000 LNK / ACT (Green) | |
PoE-in-Use(Amber) | |
1000X SFP Interfaces | |
1000 LNK / ACT (Green) | |
Switching | |
Switch Architecture | Store-and-Forward |
Switch Fabric | 56Gbps |
Switch Throughput@64bytes | 41.66Mpps |
MAC Address Table | 8K entries |
Jumbo Frame | 9216 bytes |
Flow Control | IEEE 802.3x pause frame for full duplex; back pressure for half duplex |
Power over Ethernet | |
PoE Standard | IEEE 802.3at Power over Ethernet Plus/PSE |
PoE Injector Ports | 24 |
PoE Power Supply Type | End-span: 1/2 (+), 3/6 (-) |
PoE Power Output | Per port 54±1V DC, 300mA. max. 15.4 watts (IEEE 802.3af) |
Per port 54±1V DC, 600mA. max. 32 watts (IEEE 802.3at) | |
PoE Power Budget | 250 watts |
Number of PDs, 7 watts | 24 |
Number of PDs, 15.4 watts | 16 |
Number of PDs, 30 watts | 8 |
Standards Conformance | |
Regulatory Compliance | FCC Part 15 Class A, CE |
Standards Compliance | IEEE 802.3 10BASE-T |
IEEE 802.3u 100BASE-TX | |
IEEE 802.3ab Gigabit 1000BASE-T | |
IEEE 802.3z Gigabit SX/LX | |
IEEE 802.3x flow control and back pressure | |
IEEE 802.3af Power over Ethernet | |
IEEE 802.3at Power over Ethernet Plus | |
IEEE 802.3az Energy Efficient Ethernet | |
Environment | |
Operating | Temperature: 0 ~ 50 degrees C |
Relative Humidity: 5~ 95% (non-condensing) | |
Storage | Temperature: -10 ~ 70 degrees C |
Relative Humidity: 5 ~ 95% (non-condensing) |
Teknik Kısa
PoE : PoE Plus
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilemez
Aktarım Port Sayısı : 2
Aktarım Türü : Combo
PoE Port Sayısı : 24 Port
