HP 2920 48G PoE Plus J9836A 10/100/1000 PoE Switch
Teknik Özellikler
| Capacity |
| Type: |
| IPv4 routing table entries |
| Value: |
| 2048 |
| Type: |
| IPv6 routing table entries |
| Value: |
| 256 |
| Dimensions & Weight |
| Depth: |
| 13.2 in |
| Height: |
| 1.7 in |
| Weight: |
| 12.85 lbs |
| Width: |
| 17.4 in |
| Environmental Parameters |
| Humidity Range Operating: |
| 15 - 95% (non-condensing) |
| Humidity Range Storage: |
| 15 - 90% (non-condensing) |
| Max Operating Temperature: |
| 131 °F |
| Max Storage Temperature: |
| 158 °F |
| Min Operating Temperature: |
| 32 °F |
| Min Storage Temperature: |
| -40 °F |
| Flash Memory |
| Installed Size: |
| 1 GB |
| Header |
| Brand: |
| HPE |
| Compatibility: |
| PC |
| Country Kits: |
| United States |
| Localization: |
| English |
| Manufacturer: |
| ProCurve Networking |
| Model: |
| 2920-48G-POE+ 740 W Switch |
| Packaged Quantity: |
| 1 |
| Product Line: |
| HPE |
| Interface Provided |
| Comments: |
| PoE+ |
| Connector Type: |
| RJ-45 |
| Qty: |
| 48 |
| Type: |
| 1000Base-T |
| Connector Type: |
| SFP |
| Qty: |
| 4 |
| Qty: |
| 1 |
| Type: |
| Management |
| Connector Type: |
| Type B |
| Type: |
| Management (micro-USB) |
| Type: |
| USB |
| Miscellaneous |
| Authentication Method: |
| CHAP , Extensible Authentication Protocol (EAP) , PAP , RADIUS , Secure Shell v.2 (SSH2) , TACACS , TACACS+ |
| Compliant Standards: |
| 80 PLUS Silver , C-Tick , CISPR 24 , EN 60825-1 , EN 60950-1 , EN55022 Class A , EN55024 , FCC Part 15 B , GOST , ICES-003 Class A , IEC 60825-1 , IEC 60950-1 Second Edition , IEC 61000-3-2 , IEC 61000-3-3 , IEC 61000-4-11 , IEC 61000-4-2 , IEC 61000-4-3 , IEC |
| 61000-4-4 , IEC 61000-4-5 , IEC 61000-4-6 , IEC 61000-4-8 , RoHS , VCCI Class A |
| Encryption Algorithm: |
| SSL , TLS |
| Height (Rack Units): |
| 1 |
| Networking |
| Advanced Switching: |
| Layer 3 |
| Compliant Standards: |
| IEEE 802.1AX , IEEE 802.1D , IEEE 802.1p , IEEE 802.1Q , IEEE 802.1s , IEEE 802.1v , IEEE 802.1w , IEEE 802.3 , IEEE 802.3ab , IEEE 802.3ad (LACP) , IEEE 802.3af , IEEE 802.3at , IEEE 802.3az , IEEE 802.3u , IEEE 802.3x |
| Connectivity Technology: |
| Wired |
| Features: |
| Access Control List (ACL) support , ARP support , BOOTP support , Class of Service (CoS) , DHCP support , Energy Efficient Ethernet , Flow control , Full duplex mode , Generic Attribute Registration Protocol (GARP) , Half duplex mode , IPv6 support , Link Aggregation Control |
| Protocol (LACP) , LLDP support , Multiple Spanning Tree Protocol (MSTP) support , PoE+ , Quality of Service (QoS) , sFlow , SNTP support , STP Root Guard , Trunking , Uni-Directional Link Detection (UDLD) , VLAN support |
| Form Factor: |
| Rack-mountable |
| Jumbo Frame Support: |
| 9220 bytes |
| MAC Address Table Size: |
| 16000 entries |
| Manageable: |
| Yes |
| PoE Budget: |
| 740 W |
| Ports Qty: |
| 48 |
| Power Over Ethernet (PoE): |
| PoE+ |
| Remote Management Protocol: |
| CLI , HTTP , HTTPS , RMON 1 , RMON 2 , RMON 3 , RMON 9 , SMON , SNMP 1 , SNMP 2c , SNMP 3 , SSH , SSH-2 , Telnet , TFTP |
| Routing Protocol: |
| MLD , RIP , RIP-2 , Static IP routing |
| Stackable: |
| Stackable |
| Subcategory: |
| Network hubs and switches |
| Subtype: |
| Gigabit Ethernet |
| Type: |
| Switch |
| Performance |
| Type: |
| Throughput |
| Value: |
| 130.9 Mpps |
| Type: |
| Switching capacity |
| Value: |
| 176 Gbps |
| Ports |
| Qty: |
| 44 |
| Type: |
| 10/100/1000 (PoE+) |
| Ports (2nd) |
| Qty: |
| 4 |
| Type: |
| Combo Gigabit SFP |
| Power Device |
| Frequency Required: |
| 50/60 Hz |
| Hot-Plug: |
| Hot-plug |
| Nominal Voltage: |
| AC 120/230 V |
| Power Consumption Operational: |
| 487 Watt |
| Power Provided: |
| 1050 Watt |
| Type: |
| Internal power supply |
| Processor |
| Clock Speed: |
| 625 MHz |
| Installed Qty: |
| 1 |
| Manufacturer: |
| ARM |
| Type: |
| ARM1176 |
| RAM |
| Installed Size: |
| 512 MB |
| Technology: |
| SDRAM |
| Service & Support |
| Type: |
| Limited lifetime warranty |
| Slot Provided |
| Free Qty: |
| 2 |
| Total Qty: |
| 2 |
| Type: |
| Expansion slot |
| Free Qty: |
| 1 |
| Total Qty: |
| 1 |
| Type: |
| Stacking Module slot |
HP 2920 48G PoE Plus J9836A 10/100/1000 PoE Switch Pdf Dosyası1.02 MB
Teknik Kısa
PoE : PoE Plus
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 3
Aktarım Port Sayısı : 4
Aktarım Türü : Combo
PoE Port Sayısı :
44 Port
44 Port PoE Güç Bütçesi : 400-800 Watt
Montaj Tipi : Rack Mount
