Açıklama
HPE Aruba 5406R 44GT JL003A PoE Switch
Özellikler
- Aruba 5406R 44GT PoE+ and 4-port SFP+ (No PSU) v3 zl2 Switch JL003A
- 1 Power Supply required
- 1 - J9990A Aruba 20-port 10/100/1000BASE-T PoE+ / 4-port 1G/10GbE SFP+ MACsec v3
- zl2 Module included (min=0 \ max=4 SFP Transceivers)
- 1 - J9986A Aruba 24-port 10/100/1000BASE-T PoE+ MACsec v3 zl2 Module included
- 1 Fan Tray Included
- 1 Management module included
- 1 RJ-45 out-of-band management port
- 4U - Height
Teknik Özellikler
| Heat Dissipation |
| 2450 BTU/hr (2584.75 kJ/hr) |
| Input Voltage |
| 110 - 127 / 200 - 240 VAC, rated |
| Latency |
| 1000 Mb Latency: < 2.8 µs 10 Gbps Latency: < 1.8 µs 40 Gbps Latency: < 1.5 µs |
| Routing/switching Capacity |
| 960 Gbps |
| Switch Fabric Speed |
| 1015 Gbps |
| Throughput |
| up to 571.4 Mpps |
| Memory and Processor |
| Freescale P2020 dual core @ 1.2 GHz 16 MB flash 1 GB SD Card 4 GB DDR3 SODIMM |
| PoE Capability |
| 1,320W, depending on power supplies installed |
| Management Features |
| Aruba AirWave Network Management Aruba Central IMC - Intelligent Management Center Command-line interface Web browser Configuration menu Out-of-band management (RJ-45 Ethernet) SNMP manager Out-of-band management (serial RS-232C or micro USB) |
| Warranty Features |
| 1 year, advance replacement, 10 calendar day, phone support |
| Warranty Standard Statement |
| Limited Lifetime Warranty: See www.hpe.com/networking/warrantysummary for warranty and support information included with your product purchase. Software releases: for details on the software releases available with your product purchase refer to www.hpe.com/networking/warrantysummary. |
| Detailed Product Description |
| Aruba 5406R v3 zl2 switch with 44 power-over-Ethernet-plus ports (without power supplies), 4 open SFP+ slots, and 4 open module slots |
| Weight (imperial) |
| 28.11 lb |
| Weight (metric) |
| 12.75 kg |
| Product Dimensions (imperial) |
| 17.5 x 17.75 x 6.9 in |
| Product Dimensions (metric) |
| 44.45 x 45.09 x 17.53 cm |
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 3
PoE Port Sayısı :
44 Port
44 Port
