1000 PoE Plus Switch

Name: Allied Telesis AT GS948MPX 10/100/1000 PoE Plus Switch
Brand: Allied Telesis

Teknik Özellikler

Device Type

Switch - 24 ports - managed - stackable

Enclosure Type

Desktop, rack-mountable 1U

Subtype

Gigabit Ethernet

Ports

24 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP + 2 x 10 Gigabit SFP+

Power Over Ethernet (PoE)

PoE+

PoE Budget

370 W

Performance

Switching fabric bandwidth : 92 Gbps ¦ Forwarding performance : 68.44 Mpps

MAC Address Table Size

16K entries

Jumbo Frame Support

9216 bytes

Routing Protocol

CIDR

Remote Management Protocol

SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, CLI

Features

Flow control, ARP support, VLAN support, IGMP snooping, Syslog support, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, IPv6 support, firmware upgradable, SNTP support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), MLD snooping, Per-VLAN Spanning Tree Plus (PVST+), STP Root Guard, SNMP trap, Energy Efficient Ethernet, Network Access Control (NAC), Strict Priority Queuing (SPQ), IP source guard, Ethernet Protection Switched Ring (EPSRing)

Compliant Standards

IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at,

IEEE 802.3az, IEEE 802.1AX

Power

AC 120/230 V ( 50/60 Hz )

Dimensions (WxDxH)

17.4 in x 14 in x 1.7 in

Weight

11.68 lbs

Localization

United States
