| Power Rating |
0.5 kVA |
| Dimensions (H x W x D) |
1.73 x 17.5 x 12.9 in. (4.4 x 44.5 x 32.8 cm.) |
| DC input voltages (RPS input) |
12 V at 4 A (-48 V at 7.8 A) |
| Operating Relative Humidity |
10% to 95% noncondensing |
| Unicast MAC Addresses |
8000 |
| Operating Temperature up to 5000 ft (1500 m) |
23 to 113 F (-5 to 45 C) |
| Available PoE Power |
370W (24 ports up to 15.4W) |
| Short-term Exception up to 10,000 feet (3000 m) |
23 to 113 F (-5 to 45 C) |
| MTBF |
180,427 hours |
| Forwarding Rate (64-byte Packet) |
13.3 mpps |
| IPv4 IGMP Groups |
255 |
| Operating Temperature up to 10,000 ft (3000 m) |
23 to 104 F (-5 to 40 C) |
| Maximum Transmission Unit (MTU) |
Up to 9000 bytes |
| Short-term Exception up to 5000 feet (1500 m) |
23 to 122 F (-5 to 50 C) |
| Voltage |
100 to 240 VAC (Autoranging); 50 to 60 Hz |
| Short-term Exception at Sea Level |
23 to 131 F (-5 to 55 C) |
| Operating Altitude |
Up to 10,000 feet (3000 m) |
| Packets per second (Mpps) |
6.5 |
| Max VLANs |
255 |
| Rack Height |
1 RU |
| AC/DC Support |
AC only |
| AC Power Supply Rating |
370 W |
| Ports |
48 PoE |
| Switching Bandwidth |
32 Gbps |
| Uplinks |
2 dual-purpose ports (10/100/1000 or SFP) - each dual-purpose uplink port has 1 10/100/1000 Ethernet port and 1 SFP-based Gigabit Ethernet port, 1 port active |
| Weight |
12 lbs (5.4 kg) |
| Short-term Exception up to 13,000 feet (4000 m) |
23 to 104 F (-5 to 40 C) |
| Storage Altitude |
Up to 13,000 feet (4000 m) |
| Memory DRAM |
64 MB |
| Storage Relative Humidity |
10% to 95% noncondensing |
| Model |
LAN Base Layer 2 |
| Forwarding Bandwidth |
16 Gbps |
| Flash Memory |
32 MB |
| Storage Temperature up to 15,000 feet (4573 m) |
-13 to 158 F (-25 to 70 C) |
| Current |
5.0 to 2.0 A |
| VLAN IDs |
4000 |
| Jumbo Frames |
9018 bytes |
