Cisco SF200E 48P PoE Switch

Teknik Özellikler

Management features
Switch layer  A network switch is a computer networking device that links networking segments. A switch has different layers, such as layer 2 (a network bridge, operating at the data link layer, interconnecting a small number of devices) and layer 4 (can act as a firewall, amongst other things). L2
Quality of Service (QoS) support Yes
Multicast support Yes
Web-based management  Using a website/web application to manage something. Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity  The number of basic switching RJ-45 Ethernet ports (sockets). 48
Basic switching RJ-45 Ethernet ports type  The type/category of basic switching RJ-45 Ethernet ports (sockets). Fast Ethernet (10/100)
Combo SFP ports quantity 2
Fast Ethernet (copper) ports quantity 48
Gigabit Ethernet (copper) ports quantity 2
Networking
Networking standards  The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g. IEEE 802.1ab,IEEE 802.1D,IEEE 802.1p,IEEE 802.1Q,IEEE 802.1s,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
Head-of-line (HOL) blocking Yes
Flow control support Yes
Port mirroring Yes
Link aggregation Yes
Broadcast storm control Yes
Rate limiting Yes
DHCP client Yes
IGMP snooping Yes
Spanning tree protocol Yes
VLAN support  A Virtual Local Area Network (VLAN) consists of a group of computers and switches that can be physically distributed over different networks and buildings, but form one LAN on a logical level. Yes
Data transmission
Throughput 10.12  Mpps
MAC address table  The MAC address is the 'Media Access Control Address'. It is a unique address given to a network interface controller (NIC) in a device. A MAC address table shows the addresses in a table format. 8192  entries
Number of VLANs 256
Number of queues 8
Number of multicast groups filtered 128
Security
Security algorithms  Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product. 802.1x RADIUS,SSH
MAC address filtering  Security access control method whereby the 48-bit address assigned to each network card is used to determine access to the network. MAC addresses are uniquely assigned to each card, so using MAC filtering on a network permits and denies network access to specific devices through the use of blacklists and whitelists. Yes
Protocols
Management protocols IGMP, SNMP
Switching protocols STP, LACP, IPv6
Design
Colour of product  The colour e.g. red, blue, green, black, white. Black
LED indicators Yes
Certification UL, CSA, FCC, CE
Performance
Internal memory  The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware. 64  MB
Flash memory 8  MB
Mean time between failures (MTBF)  Statistical model used to indicate product/mechanism reliability; expressed in hours and percentage of duty cycle. This number (in hours) does not indicate the mean time before failure for a single unit/mechanism. 51866  h
Power
AC input voltage  The voltage of the AC electricity that is inpitted into the product. 100 - 240  V
AC input frequency 50 - 60  Hz
Number of power supply units 1
Power over Ethernet (PoE)
Power over Ethernet (PoE)  The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras. Yes
Power over Ethernet (PoE) ports quantity 24
Total Power over Ethernet (PoE) budget 180  W
Weight & dimensions
Width  The measurement or extent of something from side to side. 440  mm
Depth  The distance from the front to the back of something. 350  mm
Height  The measurement of the product from head to foot or from base to top. 44  mm
Weight  Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies. 5720  g
Packaging data
Quick start guide  Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly. Yes
Read more about SF200E-48P 48-Port 10/100 Smart Switch, PoE

Teknik Kısa

PoE : PoE
Port Hızı : 100 Mbps
Aktarım Port Sayısı : 2
Aktarım Türü : Combo
Montaj Tipi : Rack Mount
PoE Port Sayısı : Tooltip 48 Port
PoE Güç Bütçesi : 130-200 Watt
