Dahua PFS5452-48GT4XF-400 PoE Switch
Özellikler
- Support static route, realizing layer 3 forwarding for network data.
- Support virtual stack, virtualizing several switches into one to improve reliability and simplify configuration and management.
- Support 10 Gbps uplink with 4 ports, realizing big data transmission without lags.
- Support various management types.
Teknik Özellikler
Performance | |
Layer | Layer 2+ |
Managed | Yes |
Hardware | |
Standard Power Supply | Yes |
PoE | Yes |
Ethernet Port | 48 |
Optical Port | 4 |
Ethernet Port Rate | 1 Gbps |
Optical Port Rate | 10 Gbps |
Modular/Fixed | Fixed |
Debugging | Debugging |
Power Supply | 100V–240V AC |
Operating Temperature | °C to 45°C (32°F to 113°F) |
Operating Humidity | 10%–90% |
Storage Temperature | –40°C to 70°C (–40°F to 158°F) |
Storage Humidity | 5%–90% |
Power Consumption | Idling: 39.7W |
Full load: 473.7W | |
Performance | |
Switching Capacity | 176 Gbps |
Packet Forwarding Rate | 130.944 Mpps |
Packet Buffer Memory | 12 Mbits |
MAC Table Size | 16K |
Router Ports | 256 |
IPv4 Routing Table | 511 |
QoS Queue | 8 |
Classification Rules | 2 |
IPv4 ACL Amount | 128 |
Traffic Limit Granularity | 64K |
ACL Traffic Limit Granularity | 64K |
Standards Compliance | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3ae, IEEE802.3x, IEEE802.3z, IEEE802.3ad, IEEE802.1P, IEEE802.1Q, IEEE802.3af, IEEE802.3at |
PoE | |
PoE Standard | IEEE802.3af, IEEE802.3at |
PoE Budget | 400W |
PoE Management | Yes |
PoE Pin Assignment | 1/2(+), 3/6(-) |
Long Distance PoE Transmission | No |
Function | |
IPv4 | ARP Proxy; |
DHCP Relay; | |
DHCP Server; | |
Static Route; | |
RIP; | |
OSPF | |
IPv6 | Support ICMPv6 |
ACL | Yes |
Jumbo Frame | 12 KB |
ARP | Static table items; |
Free ARP | |
MAC Address Table | 16K |
Spanning Tree Protocol | STP, RSTP, MSTP, ERPS |
VLAN | base on MAC/protocol/IP subnet/Strategy/port VLAN; |
Dot1q tunnel; | |
GVRP; | |
VLAN-translation; | |
MAC Adress auto learning and aging; | |
source MAC address filter | |
Flow Control | Support flow control based on IEEE802.3X |
Link Aggregation | Support IEEE 802.3ad (Link Aggregation) |
Port Mirroring | Yes |
Multicast | IGMP Snooping |
IPv6 Multicast; MLD | |
DHCP | DHCP relay; |
DHCP Server; | |
DHCP Snooping | |
Security | ACL; |
802.1x, Radius authentication; | |
DoS attack protection | |
QoS | SPQ, WRR, SP+WRR, WFQ, SP+WFQ |
ARP Table Size | 8K |
VLAN Amount | 4K |
Routing Table | 256 |
System Maintenance | upload and download of configuration file; |
upload of upgrade package; | |
system log | |
Device Management | Web; |
Telnet; | |
CLI; | |
SNMP V1/V2C/V3 | |
General | |
ESD | Air discharge: 2kV |
Contact discharge: 1kV | |
Thunderproof | Common mode: ±2kV |
Net Weight | 4.5 kg (9.92 lb) |
Gross Weight | 4.8 kg (10.58 lb) |
Product Dimensions | 440 mm × 330 mm × 44.5 mm (17.32" × 12.99" × 1.75") |
Packaging Dimensions | 494 mm × 482 mm × 113 mm (19.45" × 18.98" × 4.45") |
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 2 Plus
Aktarım Port Sayısı : 4
Aktarım Türü : Gbit Fiber
PoE Port Sayısı : 48 Port
PoE Güç Bütçesi : 200-400 Watt
