HP 2620 48 PoE Plus J9627A 10/100 PoE Switch
Teknik Özellikler
| General |
| Features |
| Flow control, auto-sensing per device, DHCP support, power over Ethernet (PoE), ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, IPv6 support, half duplex mode, full duplex mode, sFlow, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, PoE+, STP Root Guard, LLDP support, MAC address lockout, dynamic ARP protection, DHCP protection, per-port broadcast throttling |
| Processor |
| 1 x Freescale MPC8313 : 400 MHz |
| Compliant Standards |
| IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at |
| Device Type |
| Switch - 48 ports - L4 - Managed |
| Enclosure Type |
| Desktop, rack-mountable 1U |
| Remote Management Protocol |
| SNMP 1, RMON 2, RMON, Telnet, SNMP 3, SNMP 2c, HTTPS, TFTP, SMON |
| RAM |
| 512 MB |
| Flash Memory |
| 512 MB |
| MAC Address Table Size |
| 16000 entries |
| Encryption Algorithm |
| SSL |
| Routing Protocol |
| RIP-1, RIP-2, IGMPv3, MLDv2, MLD |
| Authentication Method |
| RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Performance |
| Routing/switching capacity: 17.6 Gbps |
| Throughput: up to 13 Mpps |
| Power Over Ethernet (PoE) |
| PoE |
| Ports |
| 48 x 10/100 (PoE) + 2 x 10/100/1000 + 2 x SFP |
| Jumbo Frame Support |
| 9220 bytes |
| Subtype |
| Fast Ethernet |
| Expansion / Connectivity |
| Interfaces |
| 48 x 10Base-T/100Base-TX - RJ-45 - PoE |
| 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 |
| 1 x console - RJ-45 - management |
| Miscellaneous |
| Compliant Standards |
| FCC Class A certified, CISPR 22 Class A, CISPR 24, EN 60950, EN 61000-3-2, EN55022, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, VCCI Class A ITE, IEC 60950, EN |
| 61000-3-3, EN55024, UL 60950, CSA 22.2 No. 60950, EN 60825 |
| Rack Mounting Kit |
| Included |
| Power |
| Power Device |
| External power adapter |
| Voltage Required |
| AC 120/230 V ( 50/60 Hz ) |
| Environmental Parameters |
| Min Operating Temperature |
| 0 °C |
| Max Operating Temperature |
| 55 °C |
| Humidity Range Operating |
| 15 - 95% (non-condensing) |
| Min Storage Temperature |
| -40 °C |
| Max Storage Temperature |
| 70 °C |
| Humidity Range Storage |
| 15 - 90% (non-condensing) |
| Dimensions & Weight |
| Width |
| 44.3 cm |
| Depth |
| 36.8 cm |
| Height |
| 4.4 cm |
| Weight |
| 5.2 kg |
Teknik Kısa
PoE : PoE
Port Hızı : 100 Mbps
Yönetilebilirlik : Yönetilebilir Layer 4
Aktarım Port Sayısı : 4
Aktarım Türü : Gbit Fiber
Montaj Tipi : Rack Mount
PoE Port Sayısı :
48 Port
48 Port
