HP 3600 48 PoE Plus v2 EI JG302A 10/100 PoE Switch

Name: HP 3600 EI JG302A 10/100 PoE Switch
Brand: HP

Teknik Özellikler

Ürün Tanımı

3600-48-POE+ V2 EI SWITCH

Cihaz Tipi

SWITCH - 48 PORTS - MANAGED - STACKABLE

Kutu Tipi

RACK-MOUNTABLE - 1U

PORT

48 X 10/100 + 4 X GIGABIT SFP + 2 X SHARED 10/100/1000

POWER OVER ETHERNET (POE)

POE+

Performans

THROUGHPUT : 13.1 MPPS

ROUTING/SWITCHING CAPACITY : 17.6 GBPS

Kapasite

ROUTING TABLE ENTRIES : 12000

Mac Adres Tablo Boyutu

32000 ENTRIES

JUMBO Çerçeve Desteği

9216

Yönlendirme Protokolü

OSPF, RIP-1, RIP-2, IGMPV2, IGMP, VRRP, OSPFV2, PIM-SM, PIM-DM, IGMPV3, OSPFV3, PIM-SSM, MSDP, STATIC IPV4 ROUTING, STATIC IPV6 ROUTING, ECMP, RIPNG, BGP-4+

Uzaktan Yönetim Kontrolü

SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, TELNET, SNMP 3, SNMP 2C, HTTP, HTTPS, SSH, SSH-2, CLI

Özellikler

FLOW CONTROL, DHCP SUPPORT,ARP SUPPORT, VLAN SUPPORT,AUTO-UPLINK (AUTO MDI/MDI-X), IGMP SNOOPING,IPV6 SUPPORT, HALF DUPLEX MODE, FULL DUPLEX MODE, SFLOW,SPANNING TREE PROTOCOL (STP) SUPPORT,

RAPID SPANNING TREE PROTOCOL (RSTP) SUPPORT,VIRTUAL ROUTE REDUNDANCY PROTOCOL (VRRP) SUPPORT,MULTIPLE SPANNING TREE PROTOCOL (MSTP) SUPPORT,TRIVIAL FILE TRANSFER PROTOCOL (TFTP) SUPPORT,

ACCESS CONTROL LIST (ACL) SUPPORT,QUALITY OF SERVICE (QOS), COMMITTED ACCESS RATE (CAR),JUMBO FRAMES SUPPORT, MLD SNOOPING,DEVICE LINK DETECTION PROTOCOL (DLDP) SUPPORT,

RAPID RING PROTECTION PROTOCOL (RRPP) SUPPORT,BIDIRECTIONAL FORWARDING DETECTION (BFD),ENDPOINT ADMISSION DEFENSE (EAD),STP ROOT GUARD, IPV4 SUPPORT

Standartlar

IEEE 802.3, IEEE 802.3U, IEEE 802.3I, IEEE 802.3Z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3AB, IEEE 802.1P, IEEE 802.3X, IEEE 802.3AD (LACP), IEEE 802.1W, IEEE 802.1X, IEEE 802.1S, IEEE 802.1AD, IEEE 802.1V, IEEE 802.1AB (LLDP), IEEE 802.3AT

Güç

AC 120/230 V ( 50/60 HZ )

Yaklaşık Ölçüleri (WXDXH)

17.3 IN X 16.5 IN X 1.7 IN

Yaklaşık Ağırlık

22 LBS

HP 3600 EI JG302A 10/100 PoE Switch Pdf Dosyası352.05 KB
