HPE Aruba 3810M 40G JL076A PoE Switch
Özellikler
Teknik Özellikler
| Product Differentiator (long) |
| Scalable high-end campus access switch mixing Gigabit PoE+ and Smart Rate PoE+ ports. Great for highest-speed Access Point connections in a Mobile First network. This model has 40x 10/100/1000 PoE+ ports together with 8x RJ45 HPE Smart Rate multi GbE PoE+ ports, together with 1x open module slot and a stacking module slot. Power supplies are ordered separately. When matched with the correct dual power supplies, supports up to 1440W of PoE+ power across 48 ports. |
| Input Voltage |
| 100-240 VAC Depending on installed options, model and configuration |
| Latency |
| 1000 Mb Latency: < 2.8 µs 10 Gbps Latency: < 1.8 µs 40 Gbps Latency: < 1.5 µs |
| Routing/switching Capacity |
| 480 Gbps |
| Switch Fabric Speed |
| 508 Gbps |
| Stacking Capabilities |
| Virtual 10 switches |
| Throughput |
| up to 273.8 Mpps |
| Memory and Processor |
| Dual ARM Coretex A9 @ 1 GHz 2 GB DDR3 SDRAM Packet buffer size: 13.5 MB Internal |
| PoE Capability |
| 1,440 W maximum, depending on configuration |
| Management Features |
| Aruba AirWave Network Management Aruba Central IMC - Intelligent Management Center Command-line interface Web browser Configuration menu Out-of-band management (RJ-45 Ethernet) In-line and out-of-band Out-of-band management (serial RS-232C or micro USB) |
| Warranty Standard Statement |
| Limited Lifetime Warranty: See www.hpe.com/networking/warrantysummary for warranty and support information included with your product purchase. Software releases: for details on the software releases available with your product purchase refer to www.hpe.com/networking/warrantysummary. |
| Weight (imperial) |
| 13.61 lb |
| Weight (metric) |
| 6.17 kg |
| Product Dimensions (imperial) |
| 17.42 x 16.98 x 1.73 in |
| Product Dimensions (metric) |
| 44.25 x 43.13 x 4.39 cm |
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 2
Aktarım Port Sayısı : 8
Aktarım Türü : Rj45
PoE Güç Bütçesi : 800 Watt >
