Netgear M4300 96X PoE Switch
Teknik Özellikler
Device Type | Switch - 48 ports - L3 - managed - stackable |
Enclosure Type | Rack-mountable 1U |
Subtype | 10 Gigabit Ethernet |
Ports | 48 x 10 Gigabit SFP+ |
Performance | Switching capacity: 1.92 Tbps Throughput: 2.857 Mpps 10 Gbps fiber latency (64-byte packets): 0.75 µs 10 Gbps fiber latency (512-byte packets): 1.17 µs 10 Gbps fiber latency (1024-byte packets): 1.603 µs10 Gbps fiber latency (1518-byte packets): 1.97 µs |
Capacity | Virtual interfaces (VLANs): 4093 IPv4 routes (static): 64 IPv6 routes (static): 64 RIP routes: 512 ARP entries: 8000 OSPF routes: 12000 NDP entries: 8000 |
MAC Address Table Size | 256K entries |
Jumbo Frame Support | 9KB |
Max Units In A Stack | 8 |
Routing Protocol | OSPF, RIP, IGMPv2, IGMP, VRRP, PIM-SM, PIM-DM, IGMPv3, MLDv2 |
Remote Management Protocol | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTPS, SSH, CLI |
Authentication Method | RADIUS, TACACS+ |
Features | Modular design, ARP support, DiffServ support, IPv6 support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VRRP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), MLD snooping, front to back airflow, STP Root Guard, IPv4 support, LACP support, DHCP relay, Remote Switch Port Analyzer (RSPAN), Per-VLAN Rapid Spanning Tree (PVRST), dynamic ARP protection, Neighbor Discovery Protocol (NDP), IP source guard, Bridge protocol data unit (BPDU), LISP Across Subnet Mode (ASM), Source-Specific Multicast (SSM), 96MB packet buffer |
Compliant Standards | IEEE 802.3ad (LACP), IEEE 802.3az, IEEE 802.1AX |
Processor | 1: 1.4 GHz |
RAM | 2 GB |
Flash Memory | 256 MB |
Expansion / Connectivity | |
Interfaces | 1 x management (Gigabit LAN) RJ-45 1 x serial (RS-232) RJ-45 1 x console (mini-USB) 1 x USB Type A48 x 10GBase-X SFP+ |
Expansion Slots | 12 (total) / 6 (free) |
Power | |
Power Device | Internal power supply |
Installed Qty | 1 (installed) / 2 (max) |
Power Provided | 600 Watt |
Voltage Required | AC 120/230 V |
Power Consumption Operational | 566 Watt |
Miscellaneous | |
Included Accessories | 6 x I/O module blank slot covers |
Cables Included | 1 x mini-USB type B to USB type A power cable 1 x console cable |
Rack Mounting Kit | Included |
Compliant Standards | BSMI, EN 60950, UL 1950, IEC 60950, CB, FCC CFR47 Part 15, LVD, GB4943.1-2011, RCM, BSMI CNS 14336-1, EN 61000-3-3:2013, YD/T993-1998, EN 61000-3-2:2014, CNS 13438 Class A, EN 55032:2012+AC:2013 Class A, ANSI C63.4-2014, ISED, ICES-003:2016 issue 6 Class A, CISPR 32:2012, VCCI-CISPR 32:2016 Class A, AN/NZS 60950.1:2015, AS/NZS CISPR32:2013 Class A, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, EN 55024:2010 Class A, EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, T9254-2008 (Class A) |
Localization | Europe, Americas |
Dimensions & Weight | |
Width | 21.1 in |
Depth | 17.3 in |
Height | 3.5 in |
Weight | 35.89 lbs |
Manufacturer Warranty | |
Service & Support | Limited warranty - lifetime |
Environmental Parameters | |
Min Operating Temperature | 32 °F |
Max Operating Temperature | 122 °F |
Humidity Range Operating | 95% (non-condensing) |
Min Storage Temperature | -4 °F |
Max Storage Temperature | 158 °F |
Humidity Range Storage | 95% (non-condensing) |
General | |
Authentication Method | RADIUS, TACACS+ |
Capacity | Virtual interfaces (VLANs): 4093 ¦ IPv4 routes (static): 64 ¦ IPv6 routes (static): 64 ¦ RIP routes: 512 ¦ ARP entries: 8000 ¦ OSPF routes: 12000 ¦ NDP entries: 8000 |
Compliant Standards | IEEE 802.3ad (LACP), IEEE 802.3az, IEEE 802.1AX |
Device Type | Switch - 48 ports - L3 - managed - stackable |
Enclosure Type | Rack-mountable 1U |
Features | Modular design, ARP support, DiffServ support, IPv6 support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VRRP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), MLD snooping, front to back airflow, STP Root Guard, IPv4 support, LACP support, DHCP relay, Remote Switch Port Analyzer (RSPAN), Per-VLAN Rapid Spanning Tree (PVRST), dynamic ARP protection, Neighbor Discovery Protocol (NDP), IP source guard, Bridge protocol data unit (BPDU), LISP Across Subnet Mode (ASM), Source-Specific Multicast (SSM), 96MB packet buffer |
Flash Memory | 256 MB |
Jumbo Frame Support | 9KB |
MAC Address Table Size | 256K entries |
Max Units In A Stack | 8 |
Performance | Switching capacity: 1.92 Tbps ¦ Throughput: 2.857 Mpps ¦ 10 Gbps fiber latency (64-byte packets): 0.75 µs ¦ 10 Gbps fiber latency (512-byte packets): 1.17 µs ¦ 10 Gbps fiber latency (1024-byte packets): 1.603 µs ¦ 10 Gbps fiber latency (1518-byte packets): 1.97 µs |
Ports | 48 x 10 Gigabit SFP+ |
Processor | 1: 1.4 GHz |
RAM | 2 GB |
Remote Management Protocol | SNMP 1, SNMP 2, Telnet, SNMP 3, HTTPS, SSH, CLI |
Routing Protocol | OSPF, RIP, IGMPv2, IGMP, VRRP, PIM-SM, PIM-DM, IGMPv3, MLDv2 |
Subtype | 10 Gigabit Ethernet |
Dimensions & Weight | |
Depth | 17.3 in |
Height | 3.5 in |
Weight | 35.89 lbs |
Width | 21.1 in |
Environmental Parameters | |
Humidity Range Operating | 95% (non-condensing) |
Humidity Range Storage | 95% (non-condensing) |
Max Operating Temperature | 122 °F |
Max Storage Temperature | 158 °F |
Min Operating Temperature | 32 °F |
Min Storage Temperature | -4 °F |
Expansion / Connectivity | |
Expansion Slots | 12 (total) / 6 (free) |
Interfaces | 1 x management (Gigabit LAN) RJ-45 ¦ 1 x serial (RS-232) RJ-45 ¦ 1 x console (mini-USB) ¦ 1 x USB Type A ¦ 48 x 10GBase-X SFP+ |
Manufacturer Warranty | |
Service & Support | Limited warranty - lifetime |
Miscellaneous | |
Cables Included | 1 x mini-USB type B to USB type A power cable ¦ 1 x console cable |
Compliant Standards | BSMI, EN 60950, UL 1950, IEC 60950, CB, FCC CFR47 Part 15, LVD, GB4943.1-2011, RCM, BSMI CNS 14336-1, EN 61000-3-3:2013, YD/T993-1998, EN 61000-3-2:2014, CNS 13438 Class A, EN 55032:2012+AC:2013 Class A, ANSI C63.4-2014, ISED, ICES-003:2016 issue 6 Class A, CISPR 32:2012, VCCI-CISPR 32:2016 Class A, AN/NZS 60950.1:2015, AS/NZS CISPR32:2013 Class A, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, EN 55024:2010 Class A, EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, T9254-2008 (Class A) |
Included Accessories | 6 x I/O module blank slot covers |
Localization | Europe, Americas |
Rack Mounting Kit | Included |
Power | |
Installed Qty | 1 (installed) / 2 (max) |
Power Consumption Operational | 566 Watt |
Power Device | Internal power supply |
Power Provided | 600 Watt |
Voltage Required | AC 120/230 V |
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 3
Montaj Tipi : Rack Mount
PoE Port Sayısı : 48 Port
PoE Güç Bütçesi : 400-800 Watt
