ZyXEL XGS2210 52HP 10/100/1000 PoE Switch
Özellikler
- Fully managed Layer 2 switching solution
- GbE RJ-45 and 10 GbE SFP+ connectivity
- Complies with IEEE 802.3af PoE and 802.3at PoE Plus
- High 375 W power budget
- L2 multicast, IGMP snooping, MVR and voice VLAN for convergence
- Enhanced network protection with IP source guard, DHCP snooping, ARP inspection, CPU protection
- L2, L3 and L4 filtering, MAC freeze, port isolation, guest VLAN for improved isolation and access control
- Future-proofed with IPv6 support
- Supports ZON Utility and ZyXEL One Network inter-device features for easier, more efficient setup and management
Teknik Özellikler
| Product name |
| 48-port GbE L2 PoE Switch with 10GbE Uplink |
| Switch class |
| Layer 2 |
Port Density-Total port count |
| 52 |
| 100/1000 Mbps PoE |
| 48 |
| 10 Gigabit SFP+ |
| 4 |
| Performance- Switching capacity (Gbps) |
| 176 |
| Forwarding rate (Mpps) |
| 130.9 |
| Packet buffer (byte) |
| 1.5 M |
| MAC address table |
| 16 K |
| L3 forwarding table |
| Max. 1 K IPv4 entries; Max. 512 IPv6 entries |
| Static route |
| 64 |
| IP interface |
| 32 |
| Power Input |
| 100 - 240 V AC, 50/60 Hz |
| Max. power consumption (watt) |
| 495 |
| Total PoE power budget (watt) |
| 375 |
| Physical Specifications |
| Item |
| Dimensions (WxDxH)(mm/in.) |
| 440 x 330 x 44.5/17.32 x 12.99 x 1.75 |
| Weight (kg/lb.) |
| 5.38/11.86 |
| Packing |
| Dimensions (WxDxH)(mm/in.) |
| 586 x 452 x 97/ 23.07 x 17.8 x 3.82 |
| Weight (kg/lb.) |
| 6.75/14.9 |
| Included accessories |
| • Power cord • Rack mounting kit |
| Environmental Specifications |
| Operating |
| Temperature |
| °C to 50°C/32°F to 122°F |
| Humidity |
| 10% to 95% (non-condensing) |
| Storage |
| Temperature |
| -40°C to 70°C/-40°F to 158°F |
| Humidity |
| 10% to 90% (non-condensing) |
| MTBF (hr) |
| 500,904 |
| Heat dissipation (BTU/hr) |
| 1,688 |
| Acoustic noise (dBA) |
| 57.6 |
ZyXEL XGS2210 52HP 10/100/1000 PoE Switch PDF Dosyası3.86 MB
Teknik Kısa
PoE : PoE
Port Hızı : 100 Mbps
Yönetilebilirlik : Yönetilebilir Layer 2
Aktarım Port Sayısı : 4
Aktarım Türü : Gbit Fiber
Montaj Tipi : Rack Mount
PoE Port Sayısı :
48 Port
48 Port PoE Güç Bütçesi : 200-400 Watt
