Açıklama
TP-Link TL-SF1005LP PoE Switch
Özellikler
- 5× 10/100 Mbps RJ45 ports
- 4× PoE ports transfer data and power on individual cables
- Works with IEEE 802.3af compliant PDs
- Up to 250 m data and power transmitting range under Extend Mode**
- Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application
- Supports PoE Power up to 41 W for all PoE ports*
- Plug and play with no configuration required
Teknik Özellikler
| Donanım Özellikleri | |
| Arabirim | • 5× 10/100 Mbps RJ45 Ports (Ports 1–4 support 802.3af PoE) |
| • AUTO Negotiation | |
| • AUTO MDI/MDIX | |
| Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
| • EIA/TIA-568 100Ω STP (maximum 100m) | |
| • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) | |
| • EIA/TIA-568 100Ω STP (maximum 100m) | |
| Fan Sayısı | Fanless |
| Fiziksel Güvenlik Kilidi | Yes |
| Harici Güç Kaynağı | External Power Adapter (Output: 53.5 V DC / 0.81 A) |
| Paket Yönlendirme Hızı | 0.744 Mpps |
| PoE Portları (RJ45) | • Standard: 802.3 af compliant |
| • PoE Ports: Ports 1–4 | |
| • Power Supply: 41 W | |
| MAC Adres Tablosu | 2K |
| Jumbo Frame | 2 KB |
| Switching Kapasitesi | 1 Gbps |
| Boyutlar ( W X D X H ) | 3.9×3.9×1.0 in (100×98×25 mm) |
| Maks. Güç Tüketimi | • 1.9 W (220 V / 50 Hz, no PD connected) |
| • 47 W (220 V / 50 Hz, with 41 W PD connected) | |
| Max Heat Dissipation | • 6.48 BTU/h(no PD connected) |
| • 160.27 BTU/h(with 41 W PD connected) | |
| Yazılım Özellikleri | |
| İletim Metodu | Store-And-Forward |
| Gelişmiş Fonksiyonlar | • Compatible With IEEE 802.3af/at Compliant PDs |
| • Extend Mode Button (Ports 1–4) | |
| • Priority Mode Button (Ports 1–2) | |
| • Mac Address Auto-Learning And Auto-Aging | |
| • IEEE802.3x Flow Control For Full-Duplex Mode and Backpressure for Half-Duplex Mode | |
| Diğerleri | |
| Sertifika | FCC, CE, RoHS |
| Paket İçeriği | • TL-SF1005LP |
| • Power Adapter | |
| • Installation Guide | |
| Ortam | • Operating Temperature: 0–40 ℃ (32–104 ℉) |
| • Storage Temperature: -40–70 ℃ (-40–158 ℉) | |
| • Operating Humidity: 10–90% RH non-condensing | |
| • Storage Humidity: 5–90% RH non-condensing | |
Teknik Kısa
PoE : PoE
Port Hızı : 100 Mbps
Çalışma Mesafesi : 250 Mt.
Montaj Tipi : Desk Mount
PoE Port Sayısı :
4 Port
4 Port PoE Güç Bütçesi : 50-130 Watt
