| Rack-Mount 23 in. (58.4 cm) EIA |
Included |
| Jumbo Frame Support |
9 KB |
| Routing Protocol |
Static IPv4 routing |
| Minimum Storage Temperature |
-4 F |
| Depth |
13.78 inches |
| MTBF |
100,262 hours at 45C |
| Cables Included |
1x Serial Cable |
| Capacity |
4K Active VLANs |
| Height |
1.73 inches |
| Maximum Operating Temperature |
104 F |
| MAC Address Table Size |
16k entries |
| Localization |
Chinese (simplified), English, German, French, Italian, Spanish, Japanese |
| Width |
17.3 inches |
| Enclosure Type |
Desktop, rack-mountable - 1U |
| Maxiumum Storage Temperature |
158 F |
| Ports |
48-port 10/100/1000 + 4 combo Gigabit SFP |
| Device Type |
Switch - 52 ports - L3 - managed |
| Humidity Operating Range |
10-90% (non-condensing) |
| Weight |
11.68 lbs |
| Minimum Operating Temperature |
32 F |
| Interfaces |
48 x 10BASE-T/100BASE-TX/1000BASE-T - RJ-45 - PoE; 2 x 10BASE-T/100BASE-TX/1000BASE-T - RJ-45; 1 x console - 9 pin D-Sub (DB-9) - management; 2 x SFP (mini-GBIC) |
| Humidity Storage Range |
10-90% (non-condensing) |
| Flash Memory |
16 MB |
| Voltage Required |
AC 120/230 V ( 50/60 Hz ) |
| Performance |
Switching capacity 104 Gbps | Forwarding performance (64-byte packet size) 77.38 Mpps |
| Power Device |
Internal power supply |
| Power Over Ethernet (PoE) |
PoE/PoE+ |
| Status Indicators |
Link activity, port transmission speed, system |
| Ram |
128 MB |
| Authentication Method |
Secure Shell (SSH), RADIUS, TACACS+ |
