D-Link DSS-100E-6P PoE Switch

Interface
• 6 x 10/100 Mbps ports (4 ports with PoE support)

Port Standards & Functions
• IEEE 802.3 10Base-T
• IEEE 802.3u 100Base-TX
• IEEE 802.3af/802.3at
• IEEE 802.3x Flow Control
• Auto MDI/MDIX adjustment for all ports

Performance
Switching Capacity
• 1.2 Gbps

Switching method
• Store and forward

MAC Address Table Size
• 1K Entries

Maximum 64-byte Max.packet Forwarding Rate
• 0.89 Mbps

Packet Buffer
• 56 KB

LEDs
• Per unit: Power
• Per port: Activity/Link
• Per PoE port: PoE

PoE Standard
• IEEE 802.3af
• IEEE 802.3at

PoE Capable Ports
• Ports 1~4 up to 30 watts per port

PoE Power Budget
• 55 watts

Physical/Environmental
Surge Protection
• Ports 1~4 up to 6 kV
• Ports 5~6 up to 1 kV
• AC Power Inet up to 4 kV

MTBF (Hours)
• 96 9571 hours

Heat Dissipation
• Power On (Standby, no PD device connected): 0.31 BTU/h
• Maximum: 7.73 BTU/h

Power Input
• DC power adapter: 51 V / 1.25 A

Power Consumption
• Maximum Power Consumption: 64.2 watts (PoE on), 1.57 watts (PoE off)
• Standby Power Consumption: 1.07 watts (100 V), 1.15 watts (240 V)

Dimensions (W x D x H)
• 100 mm x 100 mm x 26 mm

Weight
• 0.2005 kg

Acoustic
• 0 dB

Ventilation
• Fanless

Operating Temperature
• 0 to 40 В°C

Storage Temperature
• -40 to 70 В°C

Operating Humidity
• 0% to 95% non-condensing

Storage Humidity
• 0% to 95% non-condensing

Certificates
• CE, RoHS

Safety
• LVD
