ONV ONV-POE33006PFM PoE Switch
Özellikler
Teknik Özellikler
Model | ONV-POE33006PFM |
Interface Characteristics | |
Fixed Port | 4*10/100/1000Base-T POE ports (Data /Power) |
2*100/1000Base-X SFP ports (Data) | |
1*Console RS232 port | |
Ethernet Port | Port1-4 can support 10/100/1000Base-T(X) auto-sensing,Full/half duplex MDI/MDI-X self-adaption |
Twisted Pair Transmission | 10BASE-T: Cat3,4,5 UTP(≤100 meter) |
100BASE-TX: Cat5 or later UTP(≤100 meter) | |
1000BASE-T: Cat5e or later UTP(≤100 meter) | |
SFP Slot Port | Gigabit SFP optical fiber interface, default matching optical modules (optional order single-mode / multi-mode, single fiber / dual fiber optical module. LC) |
Optical Cable/ Distance | Multi mode: 850nm /0 ~ 550M, Single mode: 1310nm /0 ~ 40KM, 1550nm / 0 ~ 120KM. |
Chip Parameter | |
Network Management Type | L2+ |
Network Protocol | IEEE802.3 10BASE-T, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-X, IEEE802.3x |
Forwarding Mode | Store and Forward(Full Wire Speed) |
Switching Capacity | 64Gbps (Non-blocking) |
Forwarding Rate@64byte | 8.93Mpps |
MAC | 8K |
Buffer Memory | 4.1M |
Jumbo Frame | 10K |
CPU(Hz) | 500M |
DRAM | 1G |
Flash | 128M |
LED Indicator | Power:PWR (green), network : Link (yellow), fiber port: L/A (green), PoE: PoE (green) |
Reset Switch | Yes, One-button factory reset |
PoE & Power Supply | |
PoE Port | Port 1 to 4 IEEE802.3af/at @ POE |
PoE Management | PoE working status |
Delay start of power supply | |
PoE output priority configuration | |
Scheduling of PoE operation and time | |
Total power limit of PoE power supply | |
PoE output power allocation, off& af &at | |
Power Supply Pin | Default 1/2 (+), 3/6 (-) |
Max Power Per Port | 30W; IEEE802.3af/at |
Total PWR / Input Voltage | 65W/ (AC100-240V) |
Power Consumption | Standby<6W, Full load<60W |
Power Supply | Built in power supply , |
AC100~240V 50-60Hz 1A | |
Physical Parameter | |
Operation TEMP / Humidity | -20~+55°C;5%~90% RH Non condensing |
Storage TEMP / Humidity | -40~+75°C;5%~95% RH Non condensing |
Dimension (L*W*H) | 270*181*44.5mm |
Net /Gross Weight | <1.5kg / <2.0kg |
Installation | Desktop, wall-mounted, 19 inch 1U cabinet installation |
Certification & Warranty | |
Lightning protection / protection level | Lightning protection: 4KV 8/20us; Protection level: IP30 |
Certification | CCC;CE mark, commercial; CE/LVD EN60950;FCC Part 15 Class B; RoHS |
Warranty | 3 years, lifelong maintenance. |
Network Management Features | |
Interface | IEEE802.3X (Full-duplex) |
Port temperature protection setting | |
Port green Ethernet Energy-saving setting | |
Broadcast storm control based on port speed | |
The speed limit of the message flow in the access port. | |
The minimum particle size is 64Kbps. | |
Layer 3 Features | L2+ network management ,IPV4 management |
Static route, Default route @ 128 pcs, APR @ 1024 pcs | |
VLAN | 4K VLAN based on port, IEEE802.1q |
VLAN based on the protocol | |
VLAN based on MAC,QinQ configuration | |
Port configuration of Access, Trunk, Hybrid | |
Port Aggregation | LACP, Static aggregation |
Max 3 aggregation groups and 8 ports per group. | |
Spanning Tree | STP (IEEE802.1d),RSTP (IEEE802.1w),MSTP (IEEE802.1s) |
Multicast | MLD Snooping v1/v2,Multicast VLAN |
IGMP Snooping v1/v2, Max 250 multicast groups, Fast log out | |
Port Mirroring | Bidirectional data mirroring based on port |
QoS | Flow-based Rate Limiting |
Flow-based Packet Filtering | |
8*Output queues of each port | |
802.1p/DSCP priority mapping | |
Diff-Serv QoS,Priority Mark/Remark | |
Queue Scheduling Algorithm (SP, WRR, SP+WRR) | |
ACL | Port-based Issuing ACL,ACL based on port and VLAN |
L2 to L4 packet filtering, matching first 80 bytes message. Provide ACL based on MAC, Destination MAC address, IP Source, Destination IP, IP Protocol Type, TCP/UDP Port, TCP/UDP Port Range, and VLAN, etc. | |
Security | IP-MAC-VLAN-Port binding |
ARP inspection,Anti-DoS attack | |
AAA & RADIUS,MAC learning limit | |
Mac black holes,IP source protection | |
IEEE802.1X & MAC address authentication | |
Broadcast storm control,Backup for host datum | |
SSH 2.0,SSL,Port isolation,ARP message speed limit | |
User hierarchical management and password protection | |
DHCP | DHCP Client,DHCP Snooping, DHCP Server,DHCP Relay |
Management | One-key recovery |
Cable Diagnose,LLDP | |
Web Management (HTTPS) | |
NTP,System work log,Ping Test | |
CPU instant utilization status view | |
Console/AUX Modem/Telnet/SSH2.0 CLI | |
Download & Management on FTP, TFTP, Xmodem, SFTP,SNMP V1/V2C/V3 | |
ONV NMS - smart network management system platform(LLDP+SNMP) | |
System | Category 5 Ethernet network cable |
Web browser: Mozilla Firefox 2.5 or higher, Google browser chrome V42 or higher, Microsoft Internet Explorer10 or later; | |
TCP/IP, network adapter, and network operating system (such as Microsoft Windows, Linux, or Mac OS X) installed on each computer in a network |
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 2 Plus
Aktarım Port Sayısı : 2
Aktarım Türü : Gbit Fiber
Montaj Tipi : Desk Mount
PoE Port Sayısı : 4 Port
PoE Güç Bütçesi : 50-130 Watt
