Allied Telesis AT 8100L/8POE E 10/100 PoE Switch
Teknik Özellikler
| General |
| Subtype |
| Fast Ethernet |
| Ports |
| 8 x 10/100 (PoE) + 2 x combo Gigabit SFP |
| Power Over Ethernet (PoE) |
| PoE |
| Capacity |
| Virtual interfaces (VLANs) : 256 |
| Jumbo Frame Support |
| 9216 bytes |
| Authentication Method |
| RADIUS, Secure Shell v.2 (SSH2), TACACS+ |
| MAC Address Table Size |
| 16K entries |
| Authentication Method |
| RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Power Over Ethernet (PoE) |
| PoE |
| Status Indicators |
| Link activity, collision status, port transmission speed, port duplex mode, power |
| Encryption Algorithm |
| LEAP, MD5, TLS, SSL 3.0, PEAP, TTLS |
| Routing Protocol |
| RIP-1, RIP-2, static IPv4 routing |
| Jumbo Frame Support |
| 9216 bytes |
| Manufacturer |
| Allied Telesyn |
| Camera |
| Installed Size |
| 16 MB |
| Networking |
| MAC Address Table Size |
| 16K entries |
| Subcategory |
| network hubs and switches |
| Subtype |
| Fast Ethernet |
| Form Factor |
| desktop, rack-mountable |
| Type |
| switch |
| Stackable |
| stackable |
| Advanced Switching |
| Layer 4 |
| Features |
| ARP support, Access Control List (ACL) support, Network Access Protection (NAP), PoE+, Quality of Service (QoS), SNTP support, Syslog support, Trivial File Transfer Protocol (TFTP) support, VLAN support, Virtual Yol Tarifi Göster Redundancy Protocol (VRRP) support, auto-negotiation, |
| auto-uplink (auto MDI/MDI-X), BOOTP support, event log, flow control, full duplex capability, layer 4 switching, port mirroring, power over Ethernet (PoE), routing, sFlow, stackable, DHCP relay, DHCP support, DiffServ support, IPv6 support, Jumbo Frames support, LLDP |
| support, MAC address filtering |
| Compliant Standards |
| IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.1ab (LLDP), IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.2, IEEE 802.3ab, IEEE 802.3ac |
| Jumbo Frame Support |
| 9216 bytes |
| Ports Qty |
| 8 |
| Manageable |
| Yes |
| Routing Protocol |
| RIP-1, RIP-2, static IPv4 routing |
| Remote Management Protocol |
| CLI, HTTP, HTTPS, RMON, SNMP 2, SNMP 3, SSH-2, TFTP, Telnet |
| Power Over Ethernet (PoE) |
| PoE |
| Power Device |
| Nominal Voltage |
| AC 120/230 V |
| Frequency Required |
| 50/60 Hz |
| Type |
| internal power supply |
| Power |
| Power Redundancy |
| yes |
| Power Redundancy Scheme |
| 1+1 |
| Max Supported Qty |
| 2 |
| Processor |
| Clock Speed |
| 266 MHz |
| Interface Provided |
| Interface |
| console |
| Qty |
| 1, 2, 8 |
| Connector Type |
| RJ-45, SFP (mini-GBIC) |
| Comments |
| PoE, management |
| Miscellaneous |
| Rack Mounting Kit |
| included |
| Encryption Algorithm |
| LEAP, MD5, PEAP, SSL 3.0, TLS, TTLS |
| Header |
| Brand |
| Allied Telesis |
| Product Line |
| Allied Telesis AT |
| Model |
| 8100L/8POE-E |
| Country Kits |
| United States |
| Packaged Quantity |
| 1 |
| Compatibility |
| PC |
| Dimensions & Weight |
| Depth |
| 9 in |
| Width |
| 13 in |
| Height |
| 1.7 in |
| Weight |
| 5.07 lbs |
| Included accessories |
| Cables Included |
| 1 x serial cable |
| Cable Details |
| Type |
| serial cable |
| Included Qty |
| 1 |
| Ports |
| Type |
| 10/100 (PoE) |
| Qty |
| 8 |
| Performance |
| Type |
| forwarding performance, switching capacity |
| Value |
| 2.8 Gbps, 4.16 Mpps |
| Ports (2nd) |
| Type |
| combo Gigabit SFP |
| Qty |
| 2 |
| Capacity |
| Type |
| virtual interfaces (VLANs) |
| Value |
| 256 |
Teknik Kısa
PoE : PoE
Port Hızı : 100 Mbps
Yönetilebilirlik : Yönetilebilir Layer 4
Aktarım Port Sayısı : 2
Aktarım Türü : Combo
PoE Port Sayısı :
8 Port
8 Port PoE Güç Bütçesi : 50-130 Watt
Montaj Tipi : Desk Mount
Rack Mount
