| Donanım Özellikleri |
| Arabirim | • 8× 10/100 Mbps RJ45 Ports (Ports 1–4 support 802.3af PoE) |
| • AUTO Negotiation |
| • AUTO MDI/MDIX |
| Ağ Medyası | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
| • EIA/TIA-568 100Ω STP (maximum 100m) |
| • 100BASE-TX: UTP category 5, 5e cable (maximum 100m) |
| • EIA/TIA-568 100Ω STP (maximum 100m) |
| Fan Sayısı | Fanless |
| Fiziksel Güvenlik Kilidi | Yes |
| Harici Güç Kaynağı | External Power Adapter (Output: 53.5 V DC / 0.81 A) |
| Paket Yönlendirme Hızı | 1.1904 Mpps |
| PoE Portları (RJ45) | • Standard: 802.3 af compliant |
| • PoE Ports: Ports 1–4 |
| • Power Supply: 41 W |
| MAC Adres Tablosu | 2K |
| Jumbo Frame | 2 KB |
| Switching Kapasitesi | 1.6 Gbps |
| Boyutlar ( W X D X H ) | 6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm) |
| Maks. Güç Tüketimi | • 2.2 W (220 V/ 50 Hz. no PD connected) |
| • 47.1 W (220 V/ 50 Hz. with 41 W PD connected) |
| Max Heat Dissipation | • 7.5 BTU/h(no PD connected) |
| • 160.61 BTU/h(with 41 W PD connected) |
| Yazılım Özellikleri |
| İletim Metodu | Store-And-Forward |
| Gelişmiş Fonksiyonlar | • Compatible With IEEE 802.3af Compliant PDs |
| • Extend Mode Button (Ports 1–4) |
| • Priority Mode Button (Ports 1–2) |
| • Mac Address Auto-Learning and Auto-Aging |
| • IEEE802.3x Flow Control for Full-Duplex Mode and Backpressure for Half-Duplex Mode |
| Diğerleri |
| Sertifika | FCC, CE, RoHS |
| Paket İçeriği | • TL-SF1008LP |
| • Power Adapter |
| • Installation Guide |
| Ortam | • Operating Temperature: 0–40 ℃ (32–104 ℉) |
| • Storage Temperature: -40–70 ℃ (-40–158 ℉) |
| • Operating Humidity: 10–90% RH non-condensing |
| • Storage Humidity: 5–90% RH non-condensing |
