ZyXEL GS1008HP PoE Switch

Teknik Özellikler

Standard
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3 Nway auto-negotiation
IEEE 802.3x full duplex operation and flow control
IEEE 802.3az Energy Efficient Ethernet
Performance
Data transfer rate (half duplex/full duplex):
Ethernet: 10/20 Mbps
Fast Ethernet: 100/200 Mbps
Gigabit Ethernet: 1000/2000 Mbps
MAC address table: 4 K
Memory buffer: 192 KB
Switching fabric (non-blocking): 16 Gbps
Features
Compatible With IEEE 802.3af and 802.at Compliant PDs
Auto-MDI/MDIX in all ports
EEE802.3x Flow Control
IEEE 802.1p QoS
Jumbo frame support up to 9 KB
Interface
8 RJ-45 10/100/1000 Mbps Ethernet ports with auto MDI/MDIX support
PoE Ports (RJ45)
Standard: 802.3af and 802.3at compliant
8 PoE+ ports, up to 30W per port
Total PoE Budget : 60W
LED Indicator
PWR: Power
PoE MAX:
Amber: PoE power output over 50W (total budget 60W)
Per port: Link/Activity
Amber: 10/100 Mbps
Green: 1000 Mbps
Per port : PoE+
Green: PoE supported
Power Supply
AC-to-DC external power adapter
Input: 100-240 V AC
Output: 55V DC/1.3A
Item dimensions (WxDxH): 240 x 105 x 26 mm (9.45"x4.13"1.02")
Item weight: 610g ( 1.34 lb.)
Packing dimensions (WxDxH): 256 x 132 x 78 mm (10.08"x5.20"x3.07")
Packing weight: 1260 g (2.78 lb.)
Operating Environment
Temperature: 0°C to 40°C (32°F to 104°F)
Humidity: 10% to 90% (Non-condensing)
Storage Environment
Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 10% to 90% (Non-condensing)
CE, FCC, BSMI, EAC
GbE Unmanaged PoE Switch
Power adapter
Quick Start Guide

pdfZyXEL GS1008HP PoE Switch Pdf Dosyası1023.06 KB

Teknik Kısa

PoE : PoE
Port Hızı : 1 GBit
PoE Güç Bütçesi : 50-130 Watt
Yönetilebilirlik : Yönetilemez
PoE Port Sayısı : Tooltip 8 Port
