Açıklama

Ruijie RG-ES209GC-P PoE Switch

RG-ES200 Serisi IP Güvenliği için Buluttan Yönetilebilir (Cloud Managed) PoE Switch
8 x 10/100/1000Base-T port (PoE/PoE+)
1 x 10/100/1000Base-T port

PoE : PoE

PoE Plus

Port Hızı : 1 GBit

Yönetilebilirlik : Yönetilebilir Layer 2

PoE Port Sayısı : Tooltip

8 Port

PoE Güç Bütçesi : 50-130 Watt

Aktarım Port Sayısı : 1

Aktarım Türü : Gbit Fiber

Model Specifications	RG-ES209GC-P
Hardware specifications
Ports	8 10/100/1000 Base-T ports (802.3 af/at compliant), 1 10/100/1000 Base-T port
Maximum output power per PoE port	30W
Maximum PoE output power per switch	120W
Switching capacity	18Gbps
Packet forwarding rate	13.392Mpps
Surge protection	Common mode: 4KV
Electrostatic discharge	Air discharge: 6KV
Electrostatic discharge	Contact discharge: 4KV
Power consumption	≤130W
Power supply	External power adapter
Dimensions (W x D x H)	20210828mm
MTBF	>200K
Operating environment
Operating temperature	0 to 40°C
Storage temperature	-40~70ºC
Operating humidity	10% to 90% RH
Storage humidity	5% to 95% RH
Software features
MAC capacity	4K
Static MAC address	16
VLAN	Support 802.1Q VLAN
Port management	Support port status display, port traffic statistics, PoE port output power status, port duplex / negotiation rate configuration, flow control configuration, PoE output on/off
Security	Support broadcast storm suppression, port speed limit, port isolation
L2 features	Support port mirroring, loop protection, cable detection
Management	Support management and configuration through web management interface, Ruijie Cloud platform and Ruijie Cloud app
